Maintaining the container closure integrity of vials stands as a paramount concern within pharmaceutical manufacturing, crucial for upholding product quality, efficacy, and ensuring patient safety. Conventional vial leak testing methodologies possess inherent limitations in detecting microleaks, posing a potential risk to product sterility. In response to this challenge, the advent of MicroCurrent High Voltage Leak Detection (HVLD) technology presents a groundbreaking solution, boasting unparalleled sensitivity and precision in vial leak detection.

Overview of Vial Leak Testing

Vial leak testing constitutes a pivotal stage in pharmaceutical manufacturing, serving to pinpoint any potential breaches in vial integrity that could culminate in contamination or compromise product stability. Established techniques encompass visual inspection, dye ingress and other destructive methods. Nonetheless, these methods may fall short in identifying microleaks, characterized by minute defects capable of facilitating the ingress of contaminants. Hence, manufactures are now moving towards more deterministic technology that offer quantitative and reliable test results.

Vial Leak Testing using MicroCurrent HVLD Technology

MicroCurrent HVLD is a non-destructive method for assessing the integrity of container closures in non-porous pharmaceutical and parenteral products. This technique relies on the principle of electrical current to detect any leaks in a range of liquid-filled products, including those with extremely low conductivity such as sterile water for injection (WFI) and products containing proteins or suspensions.

Compared to conventional HVLD technology, MicroCurrent HVLD significantly reduces product voltage exposure to less than 5%, thereby eliminating any potential risk to the product and reducing Ozone formation during testing.

In this method, the container is scanned using high voltage probes. One side of the container is subjected to high voltage, while a ground probe is attached to the other side. If the container is intact, both sides offer complete electrical resistance, and no significant current passes through. However, if a micro-leak or fracture is present, breakdown resistance occurs, allowing current to flow through the defect.

HVLD is unique among leak detection methods as it does not require mass to pass through the defect site; instead, it transmits electricity through the crack. This sensitivity enables HVLD to detect leaks that other conventional leak test solutions may miss.

Benefits of MicroCurrent HVLD Technology

• Scalable from the R&D Laboratory to production line
• Non-destructive, non-invasive, no sample preparation
• High level of repeatability and accuracy
• Effective across all parenteral products, including extremely low conductivity liquids (WFI)
• Lower voltage exposure produces no ozone, eliminating risk to the product and environment
• Listed in USP Chapter <1207> as recommended method for parenteral liquid package integrity testing
• Robust method and approximate 3x Signal-Noise-Ratio for a wide range of product classes and package formats
• Simplifies the inspection and validation process

In the high-stakes world of pharmaceuticals and medical devices, ensuring the integrity of packages isn't a mere formality; it's a fundamental pillar of safety and efficacy. For decades, meticulous package integrity testing methods have served as the gatekeepers, diligently sniffing out potential breaches that could compromise lives and livelihoods. Yet, traditional approaches often fell short – lacking the sensitivity to detect microscopic flaws, the versatility to handle diverse package formats, and the quantitative data to provide actionable insights. In order to overcome the shortcomings of traditional methods, manufacturers now rely on non-destructive, deterministic package testing alternatives.

Helium Leak Detection - An Overview

Helium leak testing refers to the process of finding leaks in some type of enclosed or sealed system using helium as a “tracer” gas and measuring its concentration as it escapes due to leakage. It is an effective container closure integrity test method, aimed at evaluating the integrity of pharmaceutical and parenteral products. The process involves filling the package with helium and subjecting it to vacuum. A helium leak detector is then utilized to quantitatively measure the amount of helium escaping from the package, which is expressed as a leak rate. Beyond evaluating container closure integrity, helium leak testing finds applications in product design, quality analysis, failure analysis, and validation. It offers flexibility as it can be conducted with or without a test chamber, enabling testing for "in-leakage" or "out-leakage," as well as locating leaks.

Helium is considered an ideal choice of tracer gas because of multiple reasons. Helium is non-toxic, non-flammable, non-condensable and its presence in the atmosphere is not more than 5ppm. The small atomic size of helium makes it easier to pass through leaks. Since helium does not react with other materials, it is relatively safe to use. Additionally, compared to other tracer gases helium is less expensive and is available in multiple cylinder sizes.

Helium Leak Testing Using SIMS 1915

The Seal Integrity Monitoring System (SIMS) 1915+ stands out as the ideal solution for helium-based leak detection across a range of pharmaceutical and medical device packaging systems, including vials, syringes, cartridges, and blister cards. It's particularly effective for parenteral products, such as ensuring the integrity of rubber stoppers on vials or plungers on syringe assemblies.

Utilizing helium as the tracer gas, this system allows for quantitative testing that surpasses traditional methods like vacuum bubble and dye penetration tests by a significant margin. This quantitative approach facilitates direct comparisons among different packaging materials, formats, production line settings, and storage conditions, supporting the entire product lifecycle. The SIMS 1915+ offers the capability for quantitative analysis with a sensitivity level as low as 1 x 10-10 mbar/L/sec. It provides comprehensive data sets instead of simplistic pass/fail criteria and can conduct testing at room temperature.

Each SIMS 1915+ Helium Leak Testing instrument is meticulously crafted to meet client-specific standards and package configurations. We specialize in engineering custom test fixtures tailored to the components being tested, ensuring precision and accuracy to fulfill your study objectives, accommodate various package configurations, and meet quality monitoring requirements.

SIMS 1915+ Options:

• LT 80 and LT 150 Cryo-Chiller Low Temperature Add-on Modules for ultra-cold Container Closure Integrity testing using helium leak methodology.
• Various sizes of Vacuum Test Fixtures to accommodate all package types and sizes
• Custom Test Fixtures to allow Helium leak testing for non-vacuum chamber applications.
• Additional External Helium Leak standards in various leak rate ranges.
• Helium Sniffer probe – for site specific determination of leak sites.

In pharmaceutical packaging, ensuring the integrity of containers is paramount to maintaining product safety and efficacy. Various technologies and methods are employed for package integrity testing, with MicroCurrent High Voltage Leak Detection (HVLD) emerging as a reliable and efficient solution.

MicroCurrent HVLD technology is a non-destructive container closure integrity testing (CCIT) method designed to detect leaks in sealed pharmaceutical containers, such as vials, ampoules, and syringes. Unlike traditional methods like dye ingress testing or visual inspection, which may be destructive or less sensitive, MicroCurrent HVLD offers a high level of sensitivity without compromising the integrity of the package.

The technology operates by applying a high voltage potential across the container and monitoring the resulting electrical current. When a breach or defect is present in the container's seal, the electrical current will deviate from the baseline, indicating the presence of a leak. The sensitivity of MicroCurrent HVLD allows it to detect leaks as small as microns, ensuring that even minute defects are identified.

Role of MicroCurrent HVLD Technology in Pharmaceutical Package Integrity Testing

MicroCurrent HVLD technology plays a crucial role in pharmaceutical package integrity testing by offering enhanced sensitivity, allowing for the detection of even the smallest defects in packaging to mitigate the risk of product contamination or degradation. Its non-destructive testing capability ensures that tested products remain intact, facilitating their seamless progression through the manufacturing process. Additionally, the high throughput nature of MicroCurrent HVLD systems enables efficient testing of large volumes of pharmaceutical containers, making it scalable to meet high production demands. Furthermore, its compliance with regulatory standards ensures adherence to requirements for product quality and safety, while its cost-effectiveness, despite initial investment, leads to long-term economic benefits through the prevention of product loss and reduced need for retesting.

List of E-Scan Technologies offered by PTI

1. E-Scan 605: The E-Scan 605 is an entry-level solution ideal for basic container closure integrity (CCI) testing, providing rapid PASS/FAIL test results. Featuring single-channel operation and manual loading/unloading, it offers a compact footprint suitable for low- to medium-volume testing needs.

2. E-Scan 615: The E-Scan 615 is the ideal instrument for laboratory R&D QC testing and product quality monitoring of parenteral products. Testing takes literally seconds and provides operators with PASS/FAIL and supporting quantitative data

3. E-Scan 655: The E-Scan 655 is intended for in-depth analytical container closure integrity testing of parenteral products. Location defect identification is possible along with quantitative data and PASS/FAIL.

4. E-Scan RTX: Fully automated container closure integrity testing with robotic pick & place hangling. Ideal for automation it the laboratory and production line settings.

In summary, PTI's E-Scan series offers a range of MicroCurrent HVLD solutions catering to diverse pharmaceutical packaging needs, ensuring precise integrity testing while prioritizing efficiency, safety, and compliance with regulatory standards. These advanced technologies represent a pivotal step forward in safeguarding product quality and patient safety within the pharmaceutical industry.

In today's health-conscious world, the popularity of nutraceuticals – those magical molecules promising a healthier you – is exploding. From vitamin gummies to herbal concoctions, these nutritional powerhouses line our shelves, offering a convenient path to wellness. But what about the very container that holds these life-changing potions? Nutraceutical packaging comes with unique challenges and navigating them requires innovative solutions and cutting-edge testing methods.

While nutraceuticals offer a plethora of health benefits, their packaging comes with inherent risks that can compromise product quality and safety. The nutraceutical industry faces unique challenges related to packaging, including ingredient stability, contamination, and regulatory compliance. Exposure to light, moisture, and oxygen can degrade the potency of bioactive compounds, rendering the product less effective. Contamination during the manufacturing and packaging process poses a risk to consumer safety. Additionally, regulatory bodies impose stringent standards to ensure the quality and authenticity of nutraceutical products.

Methods to Ensure Integrity of Nutraceutical Packaging

To address these challenges, manufacturers are turning to advanced testing methods for package integrity. Package integrity testing involves assessing the strength and robustness of the packaging to prevent leaks, breakages, or other vulnerabilities.

1. VeriPac Series

The VeriPac series by PTI offers cutting-edge inspection systems designed for leak detection and package integrity testing. These systems employ a non-destructive and non-invasive approach, contributing to waste reduction while delivering real-time and quantitative results. The technology is based on the ASTM-approved Vacuum Decay leak test method F2338, a methodology recognized by the FDA for its reliability and accuracy.

The VeriPac testers seamlessly connect to specially designed test chambers, creating a controlled environment for the inspection process. During testing, a vacuum is applied to the package, and absolute transducer technology is employed to monitor changes in vacuum levels over a predefined test duration. This meticulous monitoring allows the system to swiftly identify leaks and defects within the package.

One of the key advantages of the VeriPac series lies in its efficiency and objectivity. The entire process is quick, eliminating the need for subjective assessments and ensuring a non-destructive testing approach. This makes the VeriPac series suitable for various testing scenarios, ranging from laboratory offline testing to the rigorous demands of 100% inline testing in production environments.

Given the adherence to the ASTM-approved Vacuum Decay leak test method F2338, these inspection systems not only meet industry standards but also comply with FDA regulations. This recognition further underscores the reliability and precision of the VeriPac series in ensuring the integrity of packages.

2.Seal-Sensor PQX Technology

The Seal-Sensor PQX is an advanced automated pouch seal quality inspection system designed for seamless integration into production lines. Leveraging Seal-SensorTM Airborne Ultrasonic technology, this cutting-edge system conducts swift online scans of final pouch seals, aligning with ASTM Test Method F3004 and FDA consensus standards. Its deterministic and quantitative approach enables the rapid identification of defects, including incomplete seals, weak areas, and concealed issues that could compromise product quality.

The system operates with remarkable efficiency, delivering pass/fail results and generating traceable data in less than a second, even at speeds of up to 350 mm/sec. This ensures a quick and reliable assessment of seal quality, contributing to enhanced overall production efficiency.

The Seal-Sensor PQX is characterized by its user-friendly design and plug-and-play functionality, making it easy to integrate into existing manufacturing setups. Its modest footprint ensures that it can be seamlessly incorporated into various production environments without occupying excessive space. In the event of a defective pouch seal, the system features a built-in reject chute that promptly removes defective pouches from the production line. This not only prevents substandard products from progressing further in the manufacturing process but also helps maintain the integrity of the overall production flow.

As the nutraceutical boom continues, innovative packaging and rigorous testing methods like VeriPac and Seal-Sensor PQX are crucial to ensure the safety, efficacy, and trust in these life-changing supplements. By prioritizing package integrity, we unlock the true potential of these wellness wonders.

Tablets and capsules, the backbone of oral medication, are commonly encapsulated in blister packs. These packs, crafted from thermoformed plastic and sealed with aluminum foil or film, offer a trifecta of advantages: protection, tamper evidence, and convenience. Shielding pharmaceuticals from physical damage, moisture, and light, blister packs ensure dosing accuracy and provide tamper evidence, instilling confidence in consumers. Furthermore, their user-friendly design facilitates easy dispensing and portability of individual doses.

Package integrity testing emerges as a critical component in pharmaceutical quality control. Compromised packaging poses multifaceted risks, including product loss, contamination, and degradation. Leaking or damaged packages can lead to economic setbacks for manufacturers and jeopardize consumer safety. Exposure to external elements such as moisture, light, or oxygen can degrade the quality of medication, compromising its therapeutic efficacy.

OptiPac Technology: Pioneering Non-Destructive Integrity Testing

The OptiPac Leak Detection System is a non-destructive container closure integrity testing method specifically designed for blister packs. Employing One-Touch Technology, OptiPac ensures a swift test cycle without the need for changeovers or sample preparation. This innovative technology enables rapid detection of sub-5-micron defects, contingent on blister cavity volume. Unlike the vacuum-based blue dye test, OptiPac applies controlled inputs and measured outputs, eliminating the complications and reliability issues associated with dye ingress methods.

Technology Overview

OptiPac employs volumetric imaging technology under vacuum, coupled with topographic imaging, to identify the presence and location of leaks. The testing process involves placing the sample on the testing area, initiating a vacuum-based measurement upon pressing the start button. As the blisters expand under vacuum, air is drawn out through any leaks present. In the case of a leak, the air escapes into the chamber, causing a collapsed blister cavity. The dynamic vacuum test sequence captures volumetric images and measurement readings, pinpointing defective blister cavities. The system delivers a clear pass/fail result, along with quantitative measurements for each package test. OptiPac systems by PTI yield definitive results based on accurate and measurable quantitative data, reliably detecting leaks down to 5 microns. The interface is user-friendly, requiring no intricate parameter adjustments for new blister packaging formats, setting it apart from other non-destructive blister package inspection systems.

OptiPac’s insightful technology offers a suite of advanced functions:

• Auto configuration for easy recipe setup and validation of new blister formats
• Auto orientation of blister packs (test blister packs in any position –no specific orientation)
• Auto calibration is an integrated one-touch function
• Advanced batch reporting with audit trail including image of blister pack and defect results

OptiPac Benefits

• Non-destructive technology - Pass/Fail results backed by quantitative test data
• Completely tool-less
• No changeover to test different blister formats
• Identifies defective cavity
• Pre-loaded recipe library with easy recipe setup and validation of new blister formats

Class III medical devices are the highest risk medical devices, as they support or sustain life, are implanted, or present potential unreasonable risk of illness or injury. Examples of Class III medical devices include:

• Pacemakers
• Defibrillators
• High-frequency ventilators
• Cochlear implants
• Fetal blood sampling monitors
• Implanted prosthetics

Because of the high risk associated with Class III medical devices, it is essential to ensure that their packaging is intact and that the devices are sterile. Class III medical devices are the most strictly regulated medical devices by the US Food and Drug Administration (FDA).

There are several challenges associated with Class III medical device package integrity testing . One challenge is that the devices themselves are often complex and delicate, making them difficult to test without damaging them. Another challenge is that the packaging for Class III medical devices must be very effective in protecting the devices, maintain the sterile barrier and protect from contamination and damage during product lifecycle until point of use. To ensure the integrity of Class III medical devices, it is important to implement a comprehensive quality control program that includes the following measures:

• Design and testing: Medical device manufacturers must design and test their devices to ensure that they meet all applicable safety and performance standards.
• Manufacturing and assembly: Medical device manufacturers must implement strict quality control measures during the manufacturing and assembly process to ensure that devices are produced consistently and to a high standard of quality.
• Packaging: Medical device manufacturers must design and test their packaging to ensure that it can protect the devices from contamination and damage during shipping and handling.
• Testing: Medical device manufacturers must test a sample of each batch of devices to ensure that they meet all applicable safety and performance standards.

Package integrity testing and seal integrity testing are crucial for medical device packages to ensure the protection of the enclosed products from external contaminants and environmental factors. Maintaining package integrity is essential to prevent the compromise of sterile barriers, safeguarding the sterility of medical devices and ensuring their efficacy in clinical applications. Additionally, these tests help meet regulatory requirements, promoting patient safety and ensuring the reliability of medical devices throughout their lifecycle

1. Vacuum Decay technology

PTI's VeriPac Vacuum Decay technology is a non-destructive, online inspection system that can be used to test the integrity of Class III medical device packaging. The VeriPac system uses a vacuum chamber to create a differential pressure between the inside and outside of the packaging. This differential pressure is then used to detect any leaks in the packaging. PTI's VeriPac system is particularly well-suited for testing Class III medical device packaging because it is able to test a wide variety of packaging materials and designs. Additionally, the VeriPac system is able to test the integrity of the packaging without damaging the packaging or the product inside.

2. Airborne Ultrasound technology

PTI's Airborne Ultrasound technology is another non-destructive, online inspection system that can be used to test the integrity of Class III medical device packaging. The Airborne Ultrasound system uses ultrasonic waves to inspect the packaging for any defects. The Airborne Ultrasound system is particularly well-suited for testing Class III medical device packaging because it is able to detect a wide variety of defects, including small holes, tears, and wrinkles. Additionally, the Airborne Ultrasound system is able to test the integrity of the packaging without damaging the packaging or the product inside.

Package integrity testing is an essential part of the quality control process for Class III medical devices. By implementing CCI testing, medical device manufacturers can help to ensure the safety and efficacy of their devices.

In the pharmaceutical industry, the safety and efficacy of products are of utmost importance, and maintaining these qualities throughout the distribution and storage chain is a critical aspect of ensuring public health. One key element in achieving this goal is the rigorous implementation of Container Closure Integrity (CCI) testing.

CCIT refers to the evaluation of the ability of a pharmaceutical package to prevent the ingress of contaminants, as well as the escape of the product, ensuring that the package maintains its integrity over time. This process is essential in safeguarding the quality and safety of pharmaceutical products, as any compromise in the packaging can lead to contamination, degradation, or other adverse effects on the medication.

Traditional Container Closure Integrity (CCI) assessment has heavily relied on destructive testing methods, such as water bath and dye tests. These approaches involve immersing packaging materials in water or applying dyes to identify potential leaks. However, these methods present significant drawbacks. They are time-consuming, requiring substantial resources for testing and result analysis, which is highly subjective and varies from operator to operator. This prolonged process can hamper production efficiency and delay product release.

Moreover, the accuracy of these methods is questionable, as they may not reliably detect all types of leaks. The subjective nature of human interpretation in analyzing results leads to potential inconsistencies and misinterpretations. Additionally, the destructive nature of these tests contributes to product loss and waste, escalating production costs and raising environmental concerns.

In the context of a growing emphasis on sustainable practices, there is a rising demand for alternative, non-destructive, and objective CCI testing approaches that can address these limitations and align with contemporary production and sustainability standards.

CCI Testing using Vacuum decay technology

To guarantee integrity and consistency of packages, the ability to precisely detect leaks and defects is necessary. Over the years industry has seen an increasing demand for non-destructive package integrity testing methods. One such method is Vacuum Decay technology.

Vacuum Decay is a test method that has been proven over decades as the most practical and sensitive vacuum-based leak test method. It is a simple test method that challenges container integrity based on fundamental physical properties. Vacuum Decay technology creates reliable and accurate quantitative results with a pass or fail determination and has been established as a non-destructive deterministic alternative method to the blue dye test. The standard vacuum decay leak test method (ASTM F2338), developed using PTI's VeriPac instruments, is recognized by the FDA as a consensus standard for container closure integrity testing. The test method is listed in ISO 11607 and referenced in the United States Pharmacopeia Chapter on CCI (USP Chapter 1207)

How does Vacuum Decay Technology work?

Under this method, the leak testers are first connected to a test chamber that is specifically designed to hold the package to be tested. Vacuum is applied to the package placed inside the test chamber. Using single or dual vacuum transducer technology test chamber and level of vacuum are monitored along with a change in vacuum over a predetermined test time. The changes in absolute and differential vacuum indicate the presence of leaks and defects within the package. This inspection method is suitable for laboratory offline testing and can be designed for manual or fully automated operation. The test cycle is non-destructive to both product and package and takes only a few seconds. It provides significant savings by not wasting products for a leak test and generates a return on investment in under six months for many products.

Key Benefits of Vacuum Decay Technology

• Non-destructive and non-invasive
• No sample preparation
• ASTM approved test method
• FDA Recognized Consensus Standard
• Allows for increased sampling
• Quantitative results
• Eliminates cost and waste of destructive testing
• Test results can be easily validated
• SPC laboratory testing or online applications

In the world of pharmaceuticals, the integrity of vial container closures is a matter of utmost importance. Vials are small, cylindrical containers made of glass or plastic, designed to store a wide range of pharmaceuticals, including vaccines, medications, and other sensitive compounds. Their significance lies in their ability to preserve the integrity and potency of these substances. Vials shield their contents from external factors like air, moisture, and contaminants, ensuring that the product remains uncontaminated and effective.

Package integrity testing of vials is crucial to maintain the high standards of pharmaceutical products. Any breach in the vial's integrity can lead to contamination, rendering the contents ineffective or even harmful. It's not just about preserving the product; it's also about ensuring the safety of the end-users. Therefore, advanced leak testing strategies play a vital role in guaranteeing that vials are sealed securely. Vial leak testing involves identifying leaks or breaches in the vial container closures. The main goal is to confirm that the closure system maintains an airtight seal, preserving the sterility and efficacy of the product. Vial leak testing can be performed using various methods, each with its own advantages and limitations.

1. PTI's MicroCurrent HVLD Technology

PTI's MicroCurrent High Voltage Leak Detection (HVLD) is a Container closure integrity testing method that plays a crucial role in ensuring vial integrity, for liquid fill applications including proteinaceous products and small molecule liquids. It operates on a fundamental principle: detecting breaches by applying high voltage to the vial's container closure. When high voltage is applied, if there is even a minor breach in the seal, the current will pass through the vial, alerting the system to potential defects. This technique is incredibly sensitive and can identify breaches that might otherwise remain undetected by traditional methods.

One key advantage of MicroCurrent HVLD is its non-destructive nature. Unlike destructive testing methods, this technology does not harm the vial or its contents in any way. This unique method utilizes about 50% less voltage and exposes the product and environment to less than 5% of the voltage when compared to conventional HVLD solutions. Its ability to pinpoint even minute defects in vial closures ensures that products maintain their sterility and efficacy.

2. PTI's VeriPac Vacuum Decay Technology

VeriPac Vacuum Decay Technology is another container closure integrity test (CCIT) used for vial leak testing, for both liquid fill and lyophilized applications. This method relies on creating a controlled environment within which the vial is tested. By introducing vacuum and pressure differentials, VeriPac can identify leaks with remarkable accuracy. If there's a breach in the vial closure, the changes in pressure within the controlled environment will be detected, indicating a potential defect.

One of the standout features of VeriPac is its ability to pinpoint defects with exceptional precision. It can detect leaks in various vial types, whether they are glass or plastic, and offers a versatile solution for pharmaceutical quality control. Like MicroCurrent HVLD, VeriPac is non-destructive, ensuring that the vials and their contents remain unaltered during the testing process. This makes VeriPac a reliable choice for pharmaceutical companies looking to maintain the highest standards of quality and safety in their products.

In the pharmaceutical industry, maintaining vial container closure integrity is paramount. The consequences of compromised vials can be detrimental, affecting not only the product but also the health and safety of the end-users. Advanced leak testing strategies, such as PTI's MicroCurrent HVLD and VeriPac Vacuum Decay technologies, provide innovative solutions to this challenge. By using these cutting-edge methods, manufacturers can ensure the highest standards of quality and safety in their products.

Food packaging is essential for protecting food from contamination, spoilage, and damage. It also plays an important role in maintaining food quality and shelf life. Package integrity is a critical factor in ensuring the safety and quality of food products. Food packaging can be made from a variety of materials, including plastic, metal, glass, and paper. The type of packaging used depends on the type of food being packaged and its intended use. For example, perishable foods, such as meat and dairy products, require packaging that can provide a barrier to moisture and oxygen to prevent spoilage. Non-perishable foods, such as canned goods and dried goods, may require less stringent packaging requirements. Packaging that goes through a processing or retort system presents yet another set of challenges to insure integrity of the package and protection of product quality.

Significance of Food Package Integrity Testing

Package integrity testing is the process of evaluating the ability of a package to protect its contents from contamination and spoilage. It is an important quality control measure that can help to ensure food safety and quality. There are a variety of different package integrity testing methods available. Some methods are destructive, while others are non-destructive. Destructive methods, such as water bath testing, involve damaging the package to test for leaks. Non-destructive methods, such as Vacuum Decay testing, do not damage the package.

Package Integrity Testing using VeriPac Vacuum Decay Technology

The VeriPac technology is a non-destructive Container Closure Integrity Test (CCIT) system that uses Vacuum Decay technology to detect leaks in food packaging. Vacuum decay is an ASTM-approved test method (F2338) that is recognized by the FDA as a consensus standard for package integrity testing.

To test a package using VeriPac technology, the package is placed in a vacuum chamber and the pressure is applied. The system then measures the rate at which the pressure in the chamber changes. If there is a leak in the package, the pressure in the chamber will increase more quickly. Vacuum Decay technology is a highly sensitive and accurate test method that can detect leaks as small as 20 microns. It is also a very versatile test method that can be used to test a wide variety of food packaging types and sizes.

• Non-destructive, non-subjective, no sample preparation.
• Deterministic, quantitative test method.
• Defect detection down to 0.2 ccm.
• High level of sensitivity, repeatability and accuracy.
• Short cycle time provides operator with PASS/FAIL result.
• Small footprint and modular portable design.
• ASTM test method and FDA standard.
• Referenced in USP 1207 guidance.

Overall, the VeriPac Vacuum Decay is a valuable tool for food manufacturers and processors who are looking to improve their quality control processes and ensure the safety and quality of their products.

In today's fast-paced world, businesses across various industries are constantly seeking ways to streamline their operations, enhance productivity, and deliver innovative solutions to their customers. To meet these demands, many companies turn to Comprehensive Integrator and Original Equipment Manufacturer (OEM) solutions. These versatile services offer a range of benefits, from reducing development time to ensuring product quality and scalability.

PTI's Integrator and OEM Solutions are designed to help manufacturers automate their package integrity testing processes. PTI offers a variety of sensory technologies, including Airborne Ultrasound, Vacuum Decay, Microcurrent HVLD, and Force Decay, that can be integrated into existing packaging lines or used to create new PIT systems. PTI also works closely with OEMs to integrate its technologies into their equipment.

PTI's Integrator and OEM Solutions offer a number of benefits, including:

• Increased productivity: By automating package integrity testing, manufacturers can free up operators to focus on other tasks, such as production or quality control.
• Improved product quality: Automated package integrity testing can help to identify and remove defective products from the production line, preventing them from reaching customers.
• Reduced costs: It can help to reduce the cost of labor and materials, as well as the risk of recalls.
• Compliance with regulations: PTI's solutions can help to ensure that products meet regulatory requirements for package integrity.

If you are a manufacturer who is looking to automate your package integrity testing process, PTI's Integrator and OEM Solutions can help. PTI has a team of experienced engineers who can help you to select the right sensory technology and integrate them into your production line. PTI also offers a variety of services, such as training and support, to help you get the most out of your PIT system.

Here are some of the specific solutions that PTI offers:

• Airborne ultrasound technology is used to inspect and analyze seals non-destructively. PTI's Seal-Scan® and Seal-Sensor products use airborne ultrasound to provide real-time seal quality inspection on the production line.
• Vacuum decay technology is used to leak test packages and containers. PTI's VeriPac platform uses vacuum decay to provide a deterministic method for leak testing that is repeatable and reliable.
• MicroCurrent HVLD technology is a CCIT test used to inspect packages for defects such as pinholes and cracks. PTI's MicroCurrent HVLD technology is non-destructive and can be used to inspect a variety of package materials.
• Force decay technology is used to measure the force required to open a package. PTI's Force Decay technology can be used to detect counterfeit products or to verify the integrity of packages.

If you are interested in learning more about PTI's Integrator and OEM Solutions, please visit our website or contact us for a consultation.

The integrity and safety of sterile products are critical in the pharmaceutical, biotechnology, and medical device industries. Sterile materials are essential in patient care, surgical procedures, and medical treatments because they are free of live germs. To ensure that these items stay contaminant-free throughout their shelf life and delivery to patients, thorough packaging integrity testing is required.

The sterile product package serves as the first line of defense against potential contaminants, safeguarding the product from environmental hazards, physical damage, and microbial ingress. Any compromise in the packaging can lead to compromised product quality, reduced efficacy, and increased risks to patient health. Therefore, comprehensive package testing is indispensable to validate the barrier properties, durability, and overall performance of the packaging materials.

This blog delves into the significance of sterile product package testing, shedding light on the various testing methods employed and the role they play in maintaining the integrity of sterile products.

Sterile package integrity testing methods:

1. Vacuum Decay technology:

Vacuum Decay technology is a non-destructive container closure integrity test (CCIT) capable of detecting leaks in nonporous, rigid or flexible packages. Vacuum Decay leak testing is conducted by placing a sample package in a well-fitting evacuation chamber, which is provided with an external vacuum source. The vacuum levels as well as the change in vacuum over a fixed test time are closely observed using single or dual vacuum transducer technology. Changes in vacuum level beyond a predetermined pass/fail limit indicate defects within the package. PTI’s VeriPac Vacuum Decay series can non-destructively test packaging down to sub-micron leak rates - making it an excellent alternative to destructive testing methods.

2. Microcurrent HVLD technology:

Microcurrent HVLD is a unique High Voltage Leak Detection technology, highly effective across all liquid filled parenteral products. Its applications include liquid-based products ranging from extremely low conductivity sterile water for injection (WFI) to large molecule-based proteinaceous products with suspensions. Its ability to detect small pinholes, micro cracks and seal defects makes it an ideal choice for testing high risk pharmaceutical and parenteral products.

In conclusion, sterile product package testing is a cornerstone of product quality assurance, safety, and regulatory compliance. By meticulously examining packaging materials, seals, and integrity, manufacturers can safeguard product sterility, extend shelf life, meet regulatory expectations, and instil confidence in their consumers. As industries continue to advance and consumer expectations rise, investing in robust sterile product container closure integrity testing methodologies remains a fundamental necessity for any organization producing and distributing sterile products.

Ensuring the integrity of container closures is a critical aspect of pharmaceutical and biotechnology industries. Maintaining the integrity of containers, such as vials, syringes, and cartridges, is essential to preserve the quality, efficacy, and safety of products throughout their entire lifecycle. Traditionally, blue dye testing has been a widely used method to detect leaks and potential breaches in container closures. However, with the ever-evolving landscape of technology and scientific advancements, it is essential to explore and embrace alternative methods that offer higher sensitivity, reliability, and efficiency.

In this blog, we will explore cutting-edge container closure integrity testing methods that go beyond the limitations of blue dye testing. While blue dye testing has served as a valuable tool for detecting gross leaks, it may not be sufficient to detect micro-leaks or hairline cracks that could lead to potential risks during storage, distribution, and administration of pharmaceutical products.

Non-destructive CCI testing methods offered by PTI:

1. Microcurrent HVLD Technology

High Voltage Leak Detection (HVLD) is a non-destructive and non-invasive container closure integrity test (CCIT) used to assess the closure integrity of parenteral product packaging, such as pre-filled syringes, vials, cartridges, ampoules, BFS, bottles, and pouches. By employing quantitative electrical conductivity measurements, this technique allows for non-destructive testing of packages.

The HVLD method involves passing micro-current signals through the sample packages. If there is a leak in the package, the electrical resistance of the sample decreases, leading to an increase in current flow. The newer MicroCurrent HVLD technology operates using approximately 50% less voltage and exposes the product and surrounding environment to less than 5% of the voltage compared to traditional HVLD solutions. This makes it a more efficient and safer option for evaluating packaging integrity in pharmaceutical and medical applications.

2. Vacuum Decay technology

Vacuum Decay has proven to be an exceptionally effective technology for detecting leak paths and ensuring the integrity of packages. One of its key advantages is the ability to provide quantitative, deterministic, and reliable test results without causing any damage to the containers being tested. The process involves placing the packages in a meticulously fitted evacuation test chamber connected to an external vacuum source. Throughout the testing, the vacuum levels are constantly monitored to detect any deviations from the predetermined target vacuum level. If a package has defects, air will escape, leading to a noticeable change in the chamber vacuum level. Conversely, non-defective packages will retain the air, ensuring the chamber vacuum level remains constant. The versatility of this method is remarkable as it can accommodate a wide range of packaging formats, including filled and sealed rigid, semi-rigid, and flexible packages made from both non-porous and porous materials.

3. Helium Leak Detection Technology

Helium leak testing is the method of locating leaks in various enclosed or sealed systems by using helium as a "tracer" gas and measuring the concentration of the gas as it escapes due to a leak. Helium is used as a tracer gas because it is non-toxic, non-flammable, and non-condensable, and its atmospheric concentration is less than 5 ppm. Helium, as the second-smallest molecule in the periodic table, can flow through practically any defect or openings. Furthermore, because it does not react with other compounds, helium is relatively safe to use. To find and measure the leak, a mass spectrometer leak detector (MSLD), also known as a helium leak detector, is used.

4. Volumetric Imaging Technology

The OptiPac One-Touch Tool-less technology is intended for non-destructive leak detection of blister packages. To identify leaks, the OptiPac uses volumetric imaging technology to measure the motion of a blister package under vacuum. With new blister package formats, the interface is practical and straightforward to set up, requiring no tooling changeover or extensive parameter modifications as seen with previous non-destructive blister package integrity testing systems. The system collects volumetric data from each cavity, responding to variable cavity shapes, sizes, and configurations of various blister pack forms.

In conclusion, as the pharmaceutical and biotechnology industries strive to ensure the highest standards of container closure integrity, it is evident that traditional blue dye testing alone may not be sufficient to detect all potential risks. Fortunately, cutting-edge container closure integrity (CCI) methods offer superior sensitivity, reliability, and efficiency, surpassing the limitations of blue dye testing.

Packaging is a crucial aspect of the nutritional product industry, as it not only protects the product but also serves as a means to attract customers and communicate important information about the product. The packaging of nutritional products should be designed to preserve the quality, freshness and integrity of the product, while also being visually appealing, informative, and convenient for the consumer.

Nutritional product packaging can vary greatly depending on the type of product, its intended use, and the target market. Packaging materials can also play a significant role in the nutritional product industry, as they must be compatible with the product, safe for consumers, and sustainable. Some common packaging materials include plastic, glass, metal, and paper, each with its own advantages and disadvantages.

Most nutritional products are shelf-stable in nature; therefore, package performance is typically a concern. Chemical reactions occur naturally in all nutritional products. Any break or breach in the nutritional packing might lead to the products deteriorating due to air, moisture, and microbial exposure. Container closure integrity testing (CCIT) of nutritional products is vital to eliminating packaging defects and the possibility of product degradation. Read on to understand how PTI's VeriPac Flex Series guarantees the integrity of packaging for nutritional products.

Nutritional Package Inspection using VeriPac Flex System

VeriPac FLEX Systems are non-destructive inspection solutions for flexible packaging that deliver a clear PASS or FAIL as well as quantitative data that correlates to a leak rate. VeriPac FLEX Systems are available in several configurations for both the leak test instrument and the test chamber capacity to accommodate a wide range of package specifications and test sensitivity requirements, with solutions ranging from small format sachets and stick packs to very large bulk size pouches and bags.

They provide unparalleled sensitivity, reliability and practicality in testing a wide range of flexible package formats and is recognized by the FDA as a consensus standard for package integrity testing. The VeriPac tester is used to detect leaks in packages and is connected to the appropriate FLEX chamber based on the package size. There are several VeriPac configurations available with different leak detection capabilities depending on the application. The integrated flexible test chamber (IFC) is used for sachets or stick packs with low headspace, while the Drawer Style test chamber (D-Series) is available in sevearl standard sizes for other package sizes. Automated platforms for the VeriPac FLEX technology are also available for automated robotic handling of the pouches.

The VeriPac FLEX systems are unique in that they use a flexible membrane that conforms to the package shape and size, preventing stress and damage to the film materials. Multiple packages can be tested at once in a single test cycle. Custom designs can also be manufactured for large package formats and bulk products.

Benefits of VeriPac Flex Series

The test method is deterministic and quantitative.

It is non-destructive, non-subjective, and requires no sample preparation.

The method can test multiple packages in a single test cycle.

It is a cost-effective method that offers a rapid return on investment.

The method supports sustainable packaging and zero waste initiatives.

It simplifies the inspection and validation process.

The results are accurate and repeatable.

The method conforms to ASTM test method and FDA standard

Medical device package inspection is the process of evaluating the quality and integrity of the packaging of medical devices to ensure that they are safe for use. The packaging of medical devices is critical, as it protects the device from damage during shipping and handling, prevents contamination from external sources, and maintains the sterility of the device until it is used.

The package inspection process involves examining the packaging for any defects or damage that could compromise the integrity of the device. This includes checking for punctures, tears, or holes in the packaging material, as well as inspecting the seals and closures to ensure that they are secure and intact.

Medical device manufacturers are required to adhere to strict regulations and standards to certify that their packaging meets the necessary quality and safety requirements. Package integrity testing is an essential part of this process, as it helps identify any potential defects or issues with the packaging before the device reaches the end user.

Destructive vs Non-destructive Package Integrity Testing

Destructive package integrity testing involves damaging the package in some way to evaluate its integrity. This type of testing is typically more invasive and may not be suitable for products that need to be sold intact. An example of destructive package integrity testing is burst testing, where the package is subjected to internal pressure until it ruptures.

Non-destructive package integrity testing, on the other hand, involves evaluating the package's integrity without damaging it. This type of testing is typically less invasive and is more suitable for products that need to be sold intact. An example of non-destructive package integrity testing includes pressure decay testing, where a package is subjected to a pressure change and any leaks are detected by measuring the change in pressure.

Package Integrity Testing using Vacuum Decay Technology

Vacuum Decay is a non-destructive Container Closure Integrity Test (CCIT) that provides a definite pass/fail quantitative data along with dependable, reproducible, repeatable, and accurate results. The basic idea underlying Vacuum Decay technology is to question the integrity of containers based on their basic physical characteristics. Sample packages are first put into an evacuation test chamber that is tightly fitted and has an external vacuum source. A predetermined vacuum level is selected for the test based on the test sample and required level of sensitivity. The next step is to evacuate the test chamber and test system dead space for a certain amount of time. Differential pressure transducers are used to track changes in vacuum level over time. A pressure increase above the specified pass/fail limit indicates that the container is leaking.

Benefits of Vacuum Decay technology:

• Non-destructive, non-subjective, no sample preparation.
• Accurate, reliable, repeatable results.
• Definite pass/fail result based on quantitative test data.
• Accommodates multiple packaging formats.
• Eliminates destructive, subjective testing methods.
• Effective in detecting even minute leaks.

Packaging is an essential aspect of the meat snack product industry. Proper packaging helps maintain the quality, safety, and freshness of meat snack products, which is important for both consumer satisfaction and safety.

Modified Atmosphere Packaging (MAP) Tray Packs are a popular packaging method for fresh beef, pork, and poultry products, as well as for many other processed meats. Modified Atmosphere Packaging is a packaging technique that involves altering the composition of the atmosphere inside a package to extend the shelf life of the product. The goal of MAP is to slow down the natural degradation process of food by reducing the amount of oxygen inside the packaging and increasing the number of other gases, such as nitrogen or carbon dioxide. MAP has been widely used in the food industry for many years and is particularly useful for fresh fruits, vegetables, and meats. By reducing the amount of oxygen in the package, the growth of bacteria and fungi is slowed down, which helps to preserve the quality of the product for a longer period of time.

Advantages of MAP include:

1. Extended shelf life: MAP can significantly increase the shelf life of perishable foods, reducing the risk of spoilage and food waste.

2. Improved food safety: By creating an environment that inhibits the growth of microorganisms, MAP can reduce the risk of foodborne illnesses.

3. Reduced need for preservatives: With a longer shelf life, there is less need for the addition of chemical preservatives, which can be harmful to health.

4. Maintained food quality: MAP can help maintain the color, texture, and flavor of the food, which improves customer satisfaction.

How to Ensure Package Integrity of Meat Products.

The integrity of meat snack products can be tested using various methods including visual inspection, microbiological testing, or other non-destructive Container Closure Integrity Test (CCIT) methods. In this blog we will discuss how Vacuum Decay technology can be used to test the integrity of meat products

Vacuum Decay is a test method that has been proven over decades and further improved with new technological innovations. It involves drawing vacuum on a package within a test chamber and monitoring the vacuum level for decay, which would indicate a leak. The method established itself as a non-destructive replacement to the water bath leak test. It provides significant savings by not wasting product on a leak test and generates a return on investment in under six months for many products.

Vacuum Decay's acceptance as a regulatory tool is evident, and continued development optimizes the technology so that it can do more, perform better, and perform faster. PTI’s next generation of improvements are not incremental improvements, but rather foundational shifts in how the technology will serve the food, pharmaceutical, and medical device industries.

The next generation of VeriPac test systems has undergone a technology overhaul across the product line, improving each model to better perform for their respective applications. Innovation in the field of vacuum decay has often been focused on improving the practicality and sensitivity of the test method. The next generation of VeriPac systems combine both technological innovation and practical adjustments to current technology to make it the most sensitive and versatile vacuum-based leak detection technology to date. Through the introduction of unique test cycles, pneumatic controls, and processing algorithms, the VeriPac Vacuum Decay Technology is establishing itself as the foremost vacuum-based leak detection technology.

Benefits of Vacuum Decay technology:

• Non-destructive, non-subjective, no sample preparation.
• Capable of detecting defects down to 0.05 ccm.
• Accurate, reliable, repeatable results.
• Supports sustainable packaging and zero waste initiatives.
• FDA recognized standard for package integrity testing .
• Accurate, reliable, repeatable results.
• ASTM test method F2338

PTI is a group of researchers, engineers, and professionals who are dedicated to enhancing the overall package quality experience over the course of the packaging lifecycle. To ensure container closure integrity, PTI has created and developed a number of inspection technology platforms. Each technology is based on the principle that there cannot be a test method without a valid test method. The technology solutions provided by PTI are centred on container closure integrity and give a deterministic measurement of package performance needed by critical applications. By delivering package performance data from the development stage to in-production online package inspection, the solutions are widely utilized to address a variety of packaging design and material difficulties.

List of CCI and Package Integrity Techniques Offered by PTI:

1. Vacuum Decay Technology

Vacuum Decay is one of the most practical and sensitive vacuum-based leak detection techniques. This test provides the most accurate, repeatable, and reliable quantitative results, along with a pass/fail determination. The ASTM F2338 standard vacuum decay test method was developed using PTI’s VeriPac instruments. Additionally, it is recognized in the United States Pharmacopeia Chapter on CCI and classified in ISO 11607. The non-destructive container closure integrity testing (CCIT) method from VeriPac can use a differential pressure or absolute pressure transducer leak test device to find package leaks and undetectable defects.

2. Microcurrent HVLD Technology

PTI packaging and inspection systems transformed the traditional HVLD method and offered a new technology for assessing the integrity of all parenteral and biological products, including low conductivity liquids such as sterile water for injection (WFI). When compared to standard HVLD solutions, this innovative technology, known as Microcurrent HVLD, uses approximately 50% less voltage and exposes the product and environment to less than 5% of that voltage. The Microcurrent HVLD test method may detect and locate pinholes, micro-cracks, stopper/plunger leaks, non-visible leaks under crimping, and a variety of other defects.

3. Helium Leak Detection Technology

Helium leak testing is the process of identifying leaks in various enclosed or sealed systems by utilizing helium as a "tracer" gas and measuring the concentration of the gas as it escapes as a result of a leak. Because it is non-toxic, non-flammable, non-condensable, and its atmospheric concentration is less than 5 ppm, helium is utilized as a tracer gas. Helium can pass through almost any cracks or openings since it is the second-smallest molecule in the periodic table. Additionally, helium is relatively safe to use because it does not react with other substances. This method uses a mass spectrometer leak detector (MSLD), also known as a helium leak detector, to locate and measure the leak.

4. Airborne Ultrasound Technology

PTI's proprietary Airborne Ultrasound technique is a non-destructive, non-invasive seal quality inspection method. Airborne Ultrasound technology offers thorough seal quality studies and is applicable to a wide range of packaging materials, including: Tyvek, paper, foil, film, aluminium, plastic, and poly. Defects of many forms, visible and invisible, leaking and non-leaking, process-related and random, can be detected. Airborne Ultrasound technology is an ASTM Test Method F3004 and an FDA-approved standard for testing seal quality.

5. Volumetric Imaging Technology

The OptiPac One-Touch Tool-less technology is intended for non-destructive leak detection of blister packages. To identify leaks, the OptiPac uses volumetric imaging technology to measure the motion of a blister package under vacuum. With new blister package formats, the interface is practical and straightforward to set up, requiring no tooling changeover or extensive parameter modifications as seen with previous non-destructive blister package inspection systems. The system collects volumetric data from each cavity, responding to variable cavity shapes, sizes, and configurations of various blister pack forms.

6. Force Decay Technology

Force Decay is a quantitative package integrity testing approach that is well-suited for low-headspace packaging. Non-porous materials, such as films, laminates, or foils, can be used in packaging formats. It does not harm or modify the sample packages because it is a non-destructive test method. When the test is finished, the packages can be returned to the batch without being discarded. The 410's force decay technology can measure force from a package's surface deflection during a conventional vacuum-based test cycle. VeriPac 410 force decay technology has been validated on a variety of package types, including: blister packs, transdermal patch sachets, and low headspace suture packs.

PTI’s continuous technology development has brought more technology and measurement solutions to market under one brand. Whether it be helium leak detection, high voltage leak detection, airborne ultrasound, or a vacuum-based solution, PTI - Science of Quality is the think tank you can rely on to provide the highest level of technology solutions for package quality. PTI continues to build on our journey, and we look forward to supporting you on yours.

Biological drug products are complex, large-molecule drugs that are derived from living organisms or their components. They are designed to mimic, augment or replace the function of naturally occurring molecules in the body. These drugs are often produced through biotechnology, which involves manipulating living cells to produce specific proteins or other molecules.

Examples of biological drug products include monoclonal antibodies, recombinant proteins, vaccines, and gene therapies. These drugs are used to treat a wide range of diseases, including cancer, autoimmune disorders, and genetic diseases.

Biological drug products are often more expensive than traditional small-molecule drugs because they are more complex to manufacture, require specialized facilities, and are subject to rigorous testing and regulatory requirements. However, they can also provide more targeted and effective treatments for certain conditions.

Package integrity testing is an essential part of ensuring the safety and efficacy of biologics. Any damage or compromise to the packaging of biologics can lead to degradation or contamination, which can impact their efficacy and safety. The choice of method depends on the specific biologic being packaged, the type of packaging used, and the regulatory requirements. It is important to perform Container Closure Integrity tests (CCIT) solutions. at multiple stages of the manufacturing process to ensure that the biologic remains safe and effective from production to patient use.

CCI Testing of Biologics using E-Scan MicroCurrent HVLD

The E-Scan 655 is a revolutionary deterministic offline micro leak test instrument that utilizes a new class of HVLD technology to inspect vials, syringes, and other liquid filled parenteral products for container closure integrity. The E-Scan 655 technology is a MicroCurrent conductivity test method, HVLDmc, that is completely non-destructive to the container and product; exposing the package and product to lower voltage than other conductivity-based solutions.

The E-Scan MicroCurrent HVLD technology is often used in the pharmaceutical industry for detecting leaks in parenteral drug products, such as vials and syringes. E-Scan MicroCurrent HVLD technology is considered to be a reliable and efficient method for leak detection, ensuring the integrity of the drug product and patient safety.

The technology uses a non-contact and non-invasive test method that requires no sample preparation. The E-Scan 655 features a fast test cycle and simple operation. Additional benefits include quick changeover and easy recipe setup to accommodate a wide range of products and applications. E-Scan MicroCurrent HVLD technology can be migrated from laboratory to 100% inline production applications.

Benefits of E-Scan MicroCurrent HVLD

• Non-destructive, non-invasive, no sample preparation.
• High level of repeatability and accuracy
• Effective across all parenteral products, including extremely low conductivity liquids (WFI).
• Lower voltage exposure produces no ozone, eliminating risk to the product and environment
• Listed in USP Chapter <1207> as recommended method for parenteral liquid package inspection.
• Robust method and approximate 3x Signal-Noise-Ratio for a wide range of product classes and package formats.
• Simplifies the inspection and validation process.

To ensure container closure integrity, PTI - Packaging Technologies & Inspection, with headquarters in Hawthorne, New York, has created and developed seven different inspection technology platforms. The technology solutions provided by PTI are centered on container closure integrity and give a deterministic measurement of package performance needed by critical applications.

Overview of technologies offered by PTI

• Vacuum Decay technology for pharmaceutical package inspection.
• Airborne Ultrasound technology for seal quality testing and analysis.
• MicroCurrent HVLD technology for high-risk parenteral applications.
• OptiPac volumetric imaging inspection technology for blister packaging.
• Automated container closure integrity testing CCIT solutions.

Industry Applications of PTI Technologies 1. Pharmaceutical

While operating under heightened legal and regulatory scrutiny, the pharmaceutical industry continues to be at the forefront of innovation in the domains of new drugs and drug delivery techniques. It is crucial that these products have extremely sterile packaging because they are used for life-saving purposes and must be completely free of contaminants for the duration of their shelf life until they reach the patient. PTI Inspection Systems' tools for testing pharmaceutical packaging are the most sensitive, dependable, and effective. PTI technologies produce quantitative test result information and are deterministic, non-destructive test methods.

2. Biotech

The biotech sector encompasses a wide range of medical techniques, including tissue regeneration, genetic editing, and stem cell therapy. Parenteral packaging, such as pre-filled syringes, vials, IV bags, and other single-use bags, are generally used to package these medications. Testing the integrity of container closures is crucial for guaranteeing the quality of all biologics, especially parenterals. PTI's technologies are the most dependable and trustworthy options available for pharmaceutical and biotech packaging applications where the results have a significant impact on stability tests, clinical trials, production performance, and patient safety.

3. Medical device

The medical device sector is critical to the health care system since it is involved in the delivery of numerous health care services. Over the last few decades, remarkable advances in medical technology have posed a challenge to the medical device packaging industr in terms of ensuring packaging quality and reliability. Although assessing package quality is crucial for all medical devices, it is especially critical for Class III medical device products. Therefore appropriate package integrity testing technologies are needed to ensure standardized packaging quality.

4. Nutrition

The nutritional market is progressive and dynamic and nutritional packages play a vital role in delivering the product safely. Most of the nutritional products are shelf-stable in nature and this is often the function of package performance. All nutritional products are subject to innate chemical reactions. Products deteriorate with the exposure to oxygen, moisture and bacteria. PTI has decades of experience designing technologies to inspect food and nutrition packages in the most efficient way possible while ensuring package and product quality. PTI is a pioneer in meeting the needs of infant nourishment packaging applications as well as the demanding specifications of this high-risk product.

PTI provides a comprehensive range of technologies for the industries indicated above. However, it is important to note that there are no one-size-fits-all solutions. Technologies that work in one field may not work in another. As a result, before finalizing any technology, manufacturers should assess industry requirements.

PTI - Packaging Technologies & Inspection - is a group of scientists, engineers, and packaging professionals who are working to improve the overall package quality experience throughout the packaging lifecycle.

To ensure container closure integrity, PTI has designed and developed seven different inspection technology platforms. Each technology is based on the idea that there cannot be a test method without a valid test method. The technology solutions provided by PTI are centred on container closure integrity testing and give a deterministic measurement of package performance needed by critical applications. By delivering package performance data from the development stage through to in-production online package inspection, the solutions are widely utilized to address a variety of packaging design and material difficulties. PTI offers services and consulting in package inspection technologies, container closure integrity and test methods for most of the package types.

List of Services Offered by PTI:

1. Feasibility Studies

The first step in assessing and choosing the optimal CCI technology and test technique for a particular application are feasibility studies. To examine and verify the performance and quality of a package, various test methods are available. The main goal of the feasibility study is to assess the client's application and identify the best inspection technology that will deliver the most precise, sensitive, and reliable data for conclusive package integrity verification.

Clients receive a clear report of a quantitative test technique from PTI's feasibility studies for container closure integrity testing (CCIT) and package quality inspection, which confirm the suggested strategy as it applies to a particular package format. Both positive control samples with certified defects and tested good test samples are used. The technology solution, a specific leak test technique, test settings, test result information, and acceptance criteria are all detailed in the report. The report on PTI's feasibility studies outlines a clear path from the client's problem description to the quantitative test methodologies and findings, as well as how to guarantee package integrity by validating a suggested strategy in relation to a particular package format.

2. Test Method Consulting

Engineers, scientists, and other specialists on PTI's staff are experts in developing test methods, consulting on them, and conducting feasibility studies for a range of applications. The report on PTI's feasibility studies outlines a clear path from the client's problem description to the quantitative test methodologies and findings, as well as how to guarantee package integrity by validating a suggested strategy in relation to a particular package format.

3. Technical Support

PTI service specialists offer remote help via a variety of virtual channels in addition to on-site service. Installation, calibration, training, and upgrades are among the remotely offered services of PTI. The GTS staff can adapt to your demands regarding service schedule. Installations, validation, and after-sale support and maintenance are all skills, our staff have received training in. This network provides services to a varied range of markets around the world.

The ability of container closure systems to maintain a sterile barrier against potential contaminants that could lower the quality of the finished product can be understood as container closure integrity. External contaminants may enter the product through even the smallest leak or breach of the sterile barrier, impairing its capacity to perform as expected. Despite being popular leak testing techniques, dye ingress and microbial ingress have been shown to produce results that are often inaccurate and subjective. Deterministic test methodologies that can be controlled, calibrated, and provide a firm determination of CCI have therefore been encouraged by regulatory bodies.

Vacuum Decay is a non-destructive container closure integrity testing (CCIT) method for detecting leak paths and package integrity. The test method is simple in principle and challenges container integrity based on fundamental physical properties. This test provides a quantitative result that is accurate, repeatable, reproducible, and reliable with a pass/fail determination.

Our line of non-destructive VeriPac package testing equipment is backed by the tradition of excellence and performance reliability that PTI brings. The FDA acknowledges the standard Vacuum Decay leak test method (ASTM F2338), which was created using PTI's VeriPac instruments, as a consensus standard for testing container closure integrity (CCI). The test method is referenced in the United States Pharmacopeia Chapter on CCI and listed in ISO 11607 (USP Chapter 1207). The test is conducted by drawing vacuum on a package inside of a test chamber, and the vacuum level is checked for any decay that might signify a leak. The technique has established itself as a non-destructive substitute for the water bath leak test. By avoiding product waste for a leak test, it offers significant savings and, for many products, achieves return on investment in less than six months.

Industry Applications:

1. Pharmaceutical Industry

Pharmaceutical manufacturers prioritize quality control and package integrity because defects in pharmaceutical product manufacturing can directly affect drug quality. Even minor defects in the packaging or container may allow outside elements or contaminants to enter the drug. A manufacturer prioritizes implementing the proper container closure system because it affects both the product and the patient. CCI testing is a non-destructive package inspection technology for detecting leaks and avoiding potential contamination. The regulatory bodies take CCI's negligence very seriously. The guidelines support deterministic, dependable test methods for measuring industry-wide quality standards.

2. Food and Nutrition Industry

Packaging is crucial to today's food and nutrition industry. Packaging serves a variety of purposes, including product safety, brand awareness, product promotion, product protection and product delivery. Food and nutrition products are packaged so that they stay fresh for the entire shelf life. However, the challenges associated with packaging food and nutrition products have increased due to frequent innovations in packaging formats and the move towards sustainable packaging materials.

In order to ensure that the products are free from any type of contamination or defect, manufacturers are encouraged to perform appropriate package integrity tests. Various Container Closure Integrity Testing techniques are now available on the market to guarantee the quality and sterility of packages for the duration of their shelf life or until they are delivered to the consumer. Vacuum Decay technology and Airborne Ultrasound technology, among other methods, are very useful in food and nutrition package inspection.

Benefits of Vacuum Decay Technology

• Non-destructive, non-invasive, no sample preparation
• Accurate, reliable, repeatable results
• Supports sustainable packaging and zero waste initiatives
• FDA recognized standard for package integrity testing
• ASTM test method F2338

It is critical that medical fluid bags and valves do not leak. IV bags, blood bags, and drainage collection bags are all examples of medical fluid bags. IV bags contain electrolytes and medications that flow from the bag into the patient's vein via a tube and a needle to provide them with life-sustaining fluids. The Food and Drug Administration (FDA) and the United States Pharmacopeia (USP) have established strict guidelines for testing container closure systems in order to ensure the safety of sterile products like IV bags. Testing these bags for leaks is critical because leaks can risk the overall sterility of the container and thus user safety.

IV Bags Testing using VeriPac 455 Series

VeriPac Vacuum Decay technology is regarded as a highly effective method for evaluating the integrity of liquid filled IV bags. This technology is recommended by UPS 1207 and is an FDA (Food and Drug Administration) consensus standard for Container Closure Integrity testing (CCIT) of high-risk package applications with fast, repeatable and reliable test results that provide quantitative and deterministic quality assurance. Being a non-destructive technique, Vacuum Decay offers a greater understanding of the packages and reduces waste. Irrespective of the defect location, this technology system can pick up both large and small defects. Additionally, PTI VeriPac system ensures leak detection and eliminates false positives by providing quantitative test data.

IV bags can be evaluated effectively using VeriPac 455 leak detection system. It is a non-destructive, non-invasive method that requires no sample preparation. Apart from package integrity testing, VeriPac 455 can be used for stability studies, clinical trial studies, quality assurance testing and production statistical process control (SPC).

Technology Overview

Under this method, a test chamber that is specifically designed to hold the package being evaluated is connected to the VeriPac 455 leak tester. The package is placed inside the test chamber to which vacuum is applied. The test chamber is observed for both vacuum level and change during a defined test time using the dual transducer technology. The presence of leaks and defects within the package is identified by monitoring changes in absolute and differential vacuum. VeriPac 455 series is designed for manual or automatic operation, and it is suitable for laboratory offline testing and QA/QC statistical process control.

Benefits of VeriPac 455 Series

• Non-destructive, non-subjective, no sample preparation
• Defect detection down to 0.01 cc/min
• Highest level of sensitivity, repeatability and accuracy
• Results proven superior to dye ingress
• Deterministic, quantitative test method
• Supports sustainable packaging and zero waste initiatives
• ASTM test method and FDA standard

There are certain aspects that need to be maintained regardless of whether you operate in the food packaging sector or the pharmaceutical products manufacturing industry to ensure that a quality product will be provided to the clients. Package integrity testing is required for items that must be packaged so that they can be sterilized and maintained sterile for a defined amount of time, throughout the product lifecycle.

Package Integrity Testing Using VeriPac 455

The VeriPac 455 is a non-destructive, non-invasive, and highly sensitive Container Closure Integrity Testing (CCIT) method that may be implemented into protocols at any stage of the handling process. Stability research, clinical trial investigations, quality assurance testing, and production statistical process control are examples of applications for this technology (SPC). Leak rates as low as 0.05 cc/min can be found with the VeriPac 455. Results have consistently outperformed and outperformed the dye ingress test in terms of accuracy.

The VeriPac 455 core technology is based on the ASTM vacuum decay leak test method (F2338-09) recognized by the FDA as a consensus standard for package integrity testing. This test method was developed using VeriPac leak test instruments. The VeriPac 455 is equipped with the patented PERMA-Vac dual vacuum transducer technology, which increases test sensitivity and yields reproducible, dependable results.

Additionally, the VeriPac 455 contains major improvements in networking and internet access that enable remote operation, system monitoring, and MES integration. Test systems can be built to operate automatically or manually. This inspection method is appropriate for QA/QC statistical process control and laboratory offline testing. The test cycle only lasts a few seconds, the results are objective, and the testing is non-destructive to the product and the package.

Inspection Criteria

• Measures seal integrity of entire container or package
• Measures and verifies container closure system integrity
• Tests for gas leaks for dry products (lyophilized vials, powder filled)
• Tests for liquid leaks (liquid filled vials, pre-filled syringes)

Benefits

• Non-destructive, non-subjective, no sample preparation
• Defect detection down to 0.01 cc/min
• Highest level of sensitivity, repeatability and accuracy
• Results proven superior to dye ingress
• Deterministic, quantitative test method
• Supports sustainable packaging and zero waste initiatives
• ASTM test method F2338 and FDA standard for package integrity testing
• Vacuum Decay technology referenced in USP 1207 guidelines

A combination product may be defined as 'a product composed of any combination of a drug and a device; a biological product and a device; a drug and a biological product; or a drug, device, and a biological product.' In simple words, a combination product is a combination of at least two product categories such as drug, device and/or biological products. Best-known examples of combination products include prefilled syringes, pen injectors, auto-injectors, inhalers, transdermal pumps and patches, and kits containing drug administration devices or components. Often termed as high-risk medical devices, combination products host various challenges for manufacturers, demanding in-depth testing and evaluation. Read on to know how manufacturers can test the integrity of combination product packages using helium leak detection.

Package Integrity Testing using Helium Leak Testing

Helium leak detection is a highly effective technique for evaluating the integrity of a wide range of complex pharmaceutical and parenteral products. Helium leak detection can be understood as the process of identifying leaks in any closed or sealed system with the help of helium gas and measuring its concentration as it escapes due to leakage. Common applications of helium leak testing include pre-filled syringes, cold form blister packs, foil pouches and many other package formats. This technology can precisely determine integrity between specific primary container closure system components, making it an ideal choice for testing the integrity of pharmaceutical products.

Why is Helium used as a Tracer Gas?

• Helium is used as a tracer gas because of certain unique qualities that make it ideal for leak testing.
• Non-toxic, non-condensable, non-flammable.
• Helium gas is inert, which means it does not interact with the components being tested.
• Since the atomic size of helium is really small, it can easily breach through pathways reliably and easily.
• Compared to other tracer gases, helium is less expensive and readily available.
• Its presence in the atmosphere is not more than ppm.

How Does Helium Leak Detection Technology Work?

The test procedure begins by filling the package with helium, which is then subject to vacuum. Then, the amount of helium escaping from the package is quantitatively measured using a helium leak detector. This is then stated as the leak rate. Apart from leak testing, helium leak detection technology is also suitable for package design, failure analysis, tooling qualification, packaging line setup and validation, and product quality monitoring. Helium leak detection per ASTM F2391, is a well-established method recognized and widely used in the pharma industry.

Applications of Helium Leak Testing

• Ensuring Container Closure Integrity
• Selecting closure formulation and configuration
• Seal integrity monitoring during stability studies
• Extremely valuable in early-stage pharmaceutical product package system development
• Continuous product quality monitoring

Blister packs are pre-formed packaging that are commonly used for tablets, capsules and certain consumer goods. They are made up of two primary components - a cavity made from a form of plastic or aluminum and a covering made from aluminum, paper or a lamination of soft foil. The cavity holds the product while the covering seals the product in the package.

While filling tablets into blister packs, the product is first fed into the desired cavities followed by sealing the cavity covering. Manufacturers of sterile pharmaceuticals highly depend on package integrity testing to verify product quality and safety.

Package Inspection Techniques

1. OptiPac Leak Detection System

OptiPac Leak Detection System is a non-destructive container closure integrity testing method developed specifically for multi-cavity blister packs. This leak detection method uses One-Touch Technology to achieve a rapid test cycle without requiring any changeover or sample preparation. Practical operation, sensitivity and reliability are the key features that make OptiPac technology ideal for blister package inspection.

To conduct the test, the operator places the blister pack on the test plate and presses the start button. The next step involves pulling vacuum to the desired vacuum level. The blisters expand under vacuum, driving air out of the blister through any leaks present. If the pack is defective, the air escapes into the chamber leaving a collapsed blister cavity. Depending on the blister cavity, OptiPac technology provides rapid detection of upto sub-5-micron defects. Additionaally, the technology displays a definitive pass/fail result along with quantitative measurement for each package tested.

2. VeriPac 410 Series

The VeriPac 410 inspection system utilizes a combination of Vacuum Decay technology and differential force measurement for container closure integrity test (CCIT) and leak detection of blister packs, sachets, and pouches with low headspace, such as transdermal patch packaging and suture packs. This technology can be used to test multiple packages in a single test cycle based on the package specifications. Additionally, it can also precisely identify which package or blister cavity is defective. VeriPac 410 inspection systems are proven to provide quantitative test results with a definitive pass/fail result. Being a non-destructive technique, VeriPac 410 allows tested products to be returned to the production line. This eliminates the cost and waste associated with destructive leak test methods. The ROI for the VeriPac 410 makes this a powerful solution for the pharmaceutical industry.

Benefits of VeriPac 410 Series

• Non-destructive, non-invasive, no sample preparation
• Non-subjective, accurate and repeatable results
• Capability to test multiple packages in a single test cycle
• Identifies which package is defective
• Simplifies the inspection and validation process
• Supports sustainable packaging initiatives
• ASTM test method and FDA standard
• Cost effective with rapid return on investment
• Scalable to automated inline testing.

Evaluating the ability of the container closure system to provide a sterile barrier and prevent leaks resulting from contamination is a crucial step towards maintaining the safety and suitability of primary packaging. United States Pharmacopeia (USP) and Food and Drug Administration (FDA), the driving forces behind container closure systems in the US, enforce strict regulations for Container Closure Integrity Testing (CCIT).

Traditionally, Dye Ingress and Microbial immersion were two popular methods to evaluate container closure integrity. However, they were probabilistic methods that lacked accuracy and provided subjective test results. In 2016, USP issued guidelines that they preferred deterministic test methods over probabilistic test methods. Examples of deterministic test methods include Vacuum Decay technology, Airborne Ultrasound technology, Helium Leak Detection etc. In this blog, we will discuss the role of VeriPac 355, which is a Vacuum Decay technology in testing container closure integrity.

CCI Testing Using VeriPac 355 Technology

The VeriPac 355 is a non-destructive technology based on the ASTM vacuum decay leak test method (F2338-09) and is recognized by the FDA as a consensus standard for package integrity testing. This micro leak detection system is applicable across a wide range of packaging formats and is specially designed to test containers for gas leaks for dry products (lyophilized vials, powder-filled) as well test for liquid leaks (non-protein based liquid-filled vials, prefilled syringes). The non-destructive nature of the technology allows it to be incorporated into protocols at any point in the handling process. VeriPac 355 technology's capability of detecting leak rates as low as 0.2 cc/min makes it an optimal quantitative test method for many pharmaceutical and food applications.

VeriPac 355 Working Principle

The VeriPac 355 leak tester is connected to a test chamber designed specially to hold the package being tested. Vacuum is then applied to the package inside the test chamber. Using a high-resolution absolute transducer technology, the test chamber is monitored for the level of vacuum as well as the change in vacuum over a predetermined test time. Although the test cycle takes only a few seconds, it produces accurate and non-subjective test results. The sensitivity of a test is a function of the sensitivity of the transducer, the package design, the package test fixture and critical test parameters of time and pressure. Test systems can be designed for manual or semi-automatic operation. This inspection method is suitable for laboratory offline testing and QA/QC statistical process control.

Inspection Criteria

• Measures seal integrity of entire container or package
• Tests for gas leaks for dry products (lyophilized vials, powder filled)
• Tests for liquid leaks (liquid filled vials, prefilled syringes)

Benefits of VeriPac 355 Series

• Non-destructive, non-subjective, no sample preparation
• Deterministic, quantitative test method
• Measures seal integrity of entire container or package
• Tests for gas leaks for dry products (lyophilized vials, powder filled)
• Tests for liquid leaks (liquid filled vials, prefilled syringes)
• Measures and verifies container closure system integrity
• Defect detection down to 0.2 ccm
• High level of sensitivity, repeatability and accuracy
• Short cycle time provides operator with PASS/FAIL result
• Small footprint and modular portable design
• ASTM test method and FDA standard

Testing the integrity of newly developed packaging is a critical step in ensuring that it serves its requirements in every situation. Packaging needs to ensure that it sustains physical and mechanical stress and keeps the contents fresh until they reach the end user. In order to understand how packaging behaves under different circumstances, flexible packaging testing is quite important. Procedures for testing flexible packs are quite different from rigid packaging. Compared to rigid packaging, flexible packaging can present unique challenges in how to test both the integrity of the package and the seal quality. Some of the solutions offered for flexible package testing by PTI.

Flexible package integrity testing techniques

1. VeriPac Flex System

PTI's VeriPac FLEX systems are versatile non-destructive CCIT methods, designed specifically for pouches and other flexible packaging with dry-filled products. The technology utilizes an ASTM method for vacuum decay leak testing (F2338) listed in ISO 11607 and recognized by the FDA as a consensus standard for package integrity testing. PTI's VeriPac FLEX Systems are available in several configurators that can accommodate various package specifications and test sensitivity requirements. Such configurators for both the leak test instrument and the test chamber capacity enable evaluation of small format sachets and stick packs, up to large bulk size pouches and bags. A unique feature of this technology is that it requires no changeover of settings or tooling and is proven to provide high levels of sensitivity, reliability and practicality in testing a complete range of flexible packaging formats and sizes.

Technology Overview

The test begins by connecting the VeriPac tester to the appropriate FLEX chamber based on the size range of the package. The two VeriPac systems paired with the FLEX chamber provide different leak detection capabilities depending on the application. While the integrated flexible test chamber (IFC) is intended for sachets or stick packs with low headspace, the Drawer Style test chamber (D-Series) is ideal for package formats and bulk products. The unique difference with VeriPac FLEX systems is how the package is tested. PTI utilizes its flexible membrane that conforms to the package shape and size, eliminating any stress and damage to the film materials. Multiple packages can be tested in a single test cycle.

Benefits of VeriPac Flex System

• Non-destructive, non-subjective, no sample preparation.
• Deterministic, quantitative test method.
• Test multiple packages in a single test cycle.
• Cost effective with rapid return on investment.
• Supports sustainable packaging and zero waste initiatives.
• Simplifies the inspection and validation process.
• Accurate and repeatable results.
• ASTM test method and FDA standard.
• USP < 1207> compliant

2. Airborne Ultrasound Technology

PTI's Airborne Ultrasound technology is a non-destructive and non-invasive seal quality inspection method. The test is conducted by allowing ultrasound waves to pass through the package seal causing the reflection of sound waves. To identify the defects, variations in the reflected signals’ strength are analyzed. PTI offers two configurations of Airborne Ultrasound testing technology; Seal-Scan® and Seal-Sensor.

Seal-Sensor™ is a deterministic, quantitative method that inspects the final pouch seal non-destructively 100% online. Seal-Sensor detects incomplete seals, partial or weak areas in seals, and many common defects in seals that appear visually acceptable yet possess defects that affect product quality, value and shelf-life.

Seal-Scan® is an Airborne Ultrasonic Technology (ABUS) that inspects and analyzes pouch seals non-destructively offline for in-depth seal quality evaluation and analysis. Seal-Scan® is a semi-automatic inspection system with x-y drive, used for the detection of seal defects, seal characterization and material analysis.

Advantages of PTI’s Seal Scan and Seal Sensor Method:

• Deterministic seal quality inspection method that produces quantitative results.
• This method works for any material type and combinations regardless of color, transparency, print, surface finish or porosity.
• Non-destructive and non-subjective test method that requires no sample preparation.
• Technology can be integrated for 100% online defect detection of the final pouch seal.
• Repeatable, reproducible and reliable results for seal quality inspection.
• Cost-effective solution for seal integrity testing and seal analysis that characterizes overall quality and uniformity of the seal.

Most powder dairy products (milk powders, infant formula, protein-based powders, etc.) require process monitoring, production control and modified atmosphere packaging (MAP) to retain their quality throughout its shelf-life or until it reaches the end-user. However, products that use MAP often have high risks of deficiencies in package quality control. Most MAP applications use Nitrogen flushing, and testing package quality involves sampling package gas content days after the product has been packaged. The protein based content of many products will allow bacteria to consume the majority of the O2 content before the increase in O2 is detected by gas testing equipment. Leaks as small as 10-20 microns will only increase the oxygen content to levels below 3%, the typical pass/fail threshold, passing defective product. Although packaging integrity testing can be conducted using traditional methods like water bath, they are only sensitive to 25-micron leaks at best. Therefore, dairy product manufacturers should use testing methods that offer highly sensitive leak testing along with the highest level of quality assurance.

Package Testing using VeriPac Test System

Vacuum Decay has been verified as the most practical and sensitive vacuum based leak test method. It is capable of creating reliable and accurate quantitative results and a pass or fail determination. The standard Vacuum Decay leak test method (ASTM F2338), developed using PTI's VeriPac instruments, is recognized by the Food and Drug Administration (FDA) as a consensus standard for container closure integrity (CCI) testing. The test method is listed in ISO 11607 and referenced in the United States Pharmacopeia Chapter on CCI (USP Chapter 1207). VeriPac series are a practical alternative to destructive testing methods that provide subjective test results and variable test standards.

PTI brings a tradition of excellence and performance reliability to our line of VeriPac non-destructive package testing equipment. PTI's VeriPac Series has the capability to non-destructively test packages at the production line with high levels of accuracy and sensitivity. Non-destructive testing not only reduces wastage, but it also allows operators to have a greater understanding of package quality. Moreover, it can accommodate multiple package formats and requires non changeover when testing different size packages.

Technology Overview

Under this technique, the VeriPac leak tester is connected to a test chamber that contains sample packages. Vacuum is applied to these packages and a dual transducer technology is used to monitor the test chamber for both the level of vacuum as well as the change in vacuum over a predetermined test time. The changes in absolute and differential vacuum indicate the presence of leaks and defects within the package. The test cycle takes only a few seconds, results are non-subjective, and testing is non-destructive to both product and package.

VeriPac Inspection system:

• Non-destructive, non-subjective, no sample preparation.
• Deterministic, quantitative test method.
• Defect detection down to 0.2 ccm.
• High level of sensitivity, repeatability and accuracy.
• Short cycle time provides operator with PASS/FAIL result.
• Small footprint and modular portable design.
• ASTM test method and FDA standard.
• Referenced in USP 1207 guidance.

Finding the appropriate packaging for perishable foods can be quite challenging for manufacturers. Apart from considering factors such as vulnerability and freshness, a food package must ensure safety throughout its shelf life or until it reaches the end-user. To ensure that the contents are not exposed to any foreign contamination, manufacturers should conduct regular tests that can evaluate the ability of the packaging in maintaining seal integrity. Package integrity testing can pinpoint the exact location of leaks which helps operators identify the problematic area and make necessary adjustments. As a result, manufacturers can be sure of the packaging quality and ensure that the customers enjoy their products in the freshest possible state.

For inspecting package integrity of food products, PTI has developed VeriPac 310 series, a non-destructive, non-invasive Container Closure Integrity Testing (CCIT) system for highly effective leak detection. It is an ASTM approved patented vacuum decay leak test method F2338-09 recognized by the FDA as a consensus standard for package integrity testing. The VeriPac 310 provides quantitative measurements for identifying package defects before critical process issues get out of control. The tests can be performed in any sequence with real-time results.

VeriPac 310 series was developed using VeriPac leak test instruments. The next generation of VeriPac systems combines both technological innovation and practical adjustments to current technology to make it the most sensitive and versatile vacuum-based leak detection technology to date. Through the introduction of unique test cycles, pneumatic controls and processing algorithms, the VeriPac technology is establishing itself as the foremost vacuum-based leak detection technology. VeriPac systems reduce waste and provide operators with a clear understanding of package quality.

Technology Overview

Under this method, VeriPac leak testers are connected to the test chamber designed to hold the sample packages. Vacuum is then applied to the package being tested. The absolute transducer technology is used to monitor the test chamber for both the level of vacuum as well as the change in vacuum over a predetermined test time. VeriPac 310 test systems are suitable for manual or automatic operation and are designed for laboratory offline testing and production applications for QA/QC statistical process control. Testing is more reliable, sensitive and efficient than destructive methods such as the water bath or burst test.

Benefits of VeriPac 310 Series

• Non-destructive, non-subjective, no sample preparation
• Deterministic, quantitative test method
• Repeatable, rapid and reliable testing
• Cost effective and economical
• Simplifies the inspection and validation process
• ASTM test method and FDA standard

Medical devices play a key role in the diagnosis and treatment of many conditions and life saving treatments. To insure patient safety, the effectiveness of such medical devices should be carefully evaluated. Package integrity testing of medical devices is a crucial part of the manufacturing process.

Medical device package testing methods offered by PTI

1. Airborne Ultrasound technology

PTI’s Airborne Ultrasound technology (ABUS) is a seal quality inspection test method, capable of non-destructively examining packaging seal quality for defects, primarily flexible packaging seals. Under this method, ultrasound waves are passed through the pouch seal, creating a reflection of sound waves. The signal strength variations are analyzed to identify the presence of seal defects. Airborne Ultrasound technology creates a quick analysis of the seal area without tampering with the packaging to identify many common seal defects, such as incomplete or missing seals, wrinkles, and channel defects. The technology is in high demand due to its applicability across several industries, specifically the medical device industry. “Ultrasound is the only technology capable of identifying what the quality of that physical bonded nature of the seal materials are,” comments Tyler Harris, applications engineer at PTI- Packaging Technologies & Inspection. Medical device packaging including TYVEK® pouches is a very common application for ABUS technology.

PTI's Seal Scan (Offline) and Seal-Sensor (Inline) technology have further redefined pouch seal integrity testing. Both these technologies utilize non-contact airborne ultrasonic testing technology. With these advancements, Airborne Ultrasound technology has positioned itself to be the most sensitive method for non-destructive seal quality testing, in both the laboratory and in automated 100% inline testing production lines. ABUS is an ASTM Test Method F3004, recognized by the FDA as a standard for seal quality inspection and also referenced in the USP 1207 chapter guidelines.

2. Vacuum Decay technology

For several decades, Vacuum Decay has been proven to be the most practical and sensitive leak detection method for medical device and pharmaceutical packaging. It is a Container Closure Integrity Test (CCIT) capable of evaluating a wide range of packaging formats including filled and sealed rigid, semi-rigid and flexible packaging made of non-porous or porous materials. Vacuum Decay, being a non-destructive test method, does not cause any damage to the package being tested. This reduces significant waste and allows operators to have a thorough understanding of package integrity and package quality.

PTI’s VeriPac inspection technique is an ASTM approved (F2338), FDA recognized testing method capable of evaluating a wide range of high-risk package applications. To conduct this test, packages are first placed in a well-fitted evacuation test chamber, which has an internal or external vacuum source. The test operator continuously monitors the vacuum levels to identify variations from a pre-determined targeted vacuum level. In the presence of a defect, air escapes from the package into the test chamber. Packages without any defect retain the air, maintaining a constant chamber vacuum level. It is an ideal solution for medical device manufacturers to assure that the product meets regulatory standards. Based on the packaging materials used and the level of test sensitivity required, manufacturers can select the appropriate VeriPac model.

Ensuring the integrity of product packages is of utmost priority to snack food manufacturers. On-the-go snack products like wafers, chips, jerky,and coffee are vulnerable to deterioration by organic components such as moisture or air. Such foreign contaminants can enter the product through defective packages and accelerate the food decomposition process. In fact, mold, oxidation, flavor degradation, and spoilage are often the direct result of compromised package integrity. These factors can create a negative impact on consumers’ perceptions of a product and brand.

It is vital for manufacturers to ensure that packaged products are properly tested for integrity to insure that products remain fresh until they reach the consumer. Today, the market offers a wide range of leak testing that is both destructive and non-destructive. However, manufacturers should realize that a method applicable for one is not ideal for another. The leak testing method chosen should be based on the specific package specification and defect rate detection. Read on to know in detail about snack food packaging integrity testing method offered by PTI.

Package testing using PTI VeriPac Vacuum Decay Series

PTI's VeriPac inspection systems are ASTM approved vacuum decay leak test method (F2338) recognized by the FDA as a consensus standard for package integrity testing. This test method was developed using VeriPac leak test instruments. Vacuum Decay technology is a container closure integrity test (CCIT) method, referenced in the new USP <1207> Chapter Guidance as a deterministic test method for package integrity testing. This method is also listed in ISO 11607.

VerIPac test systems have a proven capability to non-destructively test a wide range of packaging formats without requiring any changeover when testing different size packages. Additionally, it is also possible to test multiple packages in a single test cycle. VeriPac provides a qualitative result (PASS or FAIL) as well as quantitative data that correlates to leak rate and leak size. Being a non-destructive method, the test allows non-defected packages to be returned to the production line, thereby reducing waste and improving testing capabilities. This makes it a practical alternative to destructive testing methods like water bath and dye ingress.

Technology Overview

The process begins by connecting VeriPac leak testers to a test chamber specifically designed to hold the sample package. Vacuum is applied to the package being tested. Using a single or dual vacuum transducer technology, vacuum levels, as well as changes in vacuum over a predetermined test time, are monitored. The changes in absolute and differential vacuum indicate the presence of leaks and defects within the package. VeriPac test systems are suitable for laboratory offline testing and can be designed for manual or fully automated operation. The test cycle takes only a few seconds, is non subjective, and non-destructive to both product and package.

VeriPac Inspection system:

• Non-destructive test method that ensures quantitative test results
• FDA recognized ASTM test method
• Referenced in USP 1207 guideline
• Cost-effective with rapid return on investment
• Supports zero waste initiatives

Medical devices are available in a variety of forms with complex geometric attributes such as valves, tubes and others that can complicate the medical device testing process. Hence, medical device leak testing equipments are expected to provide high levels of sealing effectiveness and test result sensitivity to narrow down the complexities.

Medical Device Package testing using Seal Scan technology

Seal-Scan® is a deterministic, quantitative, high-resolution method based on is an Airborne Ultrasonic Technology (ABUS). It is highly effective in non-destructively inspecting and analyzing pouch seals for defects and seal integrity for consistency. Seal-Scan systems utilize the ASTM Test Method F3004-13, which is a non-destructive test method for evaluating seal quality and integrity using Airborne Ultrasound technology. The test procedure is simple, quick and requires no sample preparation. Additionally, Seal-Scan® provides advanced digital imaging software tools for process control which offers in-depth seal quality analysis.

Seal-Scan features two scan modes:

• Linear Scan (L-Scan) to simulate online defect detection (line graph)
• C-Scan for detailed seal analysis, producing pixel by pixel evaluation of seal (Opto-Acoustic image)

Technology Overview

The test beings by scanning the pouch seal or package material between two focused ultrasonic sensors. Ultrasonic waves propagate through single or multiple layers of bonded materials. As the ultrasonic waves propagate through different mediums, it causes reflections of sound waves, which reduces/eliminates signal strength. The level of signal passing through the seal is a function of the quality of the seal. Various types of defects; leaking and non-leaking, process-related and random are detectable.

Seal scan has two scan modes (L-Scan and C-Scan) that is capable of producing Opto-Acoustic images as well as detailed statistical analysis. An L-Scan is a single linear scan along the X-axis of the seal that provides a line graph of seal integrity and simulates online inspection. C-Scan produces multiple scans (along X and Y-axis of seal area) that provide a high-resolution ultrasonic image of the seal structure. This technology can be integrated into a pouch production line via the Seal-Sensor for 100% fully automated on-line seal defect detection.

Benefits of Seal Scan Technology

• Deterministic inspection method producing quantitative results.
• Works for any material and combinations, regardless of color, transparency, print, surface finish and porosity.
• Produces high resolution Opto-Acoustic image of seal.
• Characterizes overall quality and uniformity of the seal.
• ASTM Test Method F3004 and FDA recognized standard for seal quality inspection.

Medical devices and pharmaceuticals products are manufactured with zero tolerance to defects. For this reason, manufacturers give top priority to quality control procedures and regulatory standards. This is to make sure that products maintain the quality standards required for their intended use.

Packaging plays an important role in maintaining product quality and ensuring the product reaches consumers defect-free. While selecting the right packaging material is important, testing integrity of packages also holds high relevance. Traditionally, destructive testing methods like Dye Ingress and Water Bath were popular Container Closure Integrity Testing (CCIT) techniques. However, in recent years, the industry has moved towards deterministic methods to achieve more precise, reliable results.

How PTI's VeriPac Series ensure package integrity?

PTI 's VeriPac series are non-destructive, non-subjective test systems ideal for leak testing high-risk applications that require extreme levels of test reliability and accuracy. This technology uses an ASTM approved vacuum decay leak test method F2338, which is listed in ISO 11607, USP <1207>. It is an FDA recognized consensus standard for package integrity testing. Using cutting-edge innovation, VeriPac inspection systems provide repeatable, sensitive, and more robust detection of defects. VeriPac testers feature the patented PERMA-Vac manifold system and dynamic test modes that provide the ability to test a wide range of package formats including flexible, rigid and semi-rigid packaging. Apart from package integrity testing, VeriPac technology can also be used for stability studies, clinical trials, quality assurance testing and statistical process control (SPC).

Technology Overview

The test method is initiated by connecting VeriPac leak testers to a test chamber that is specially designed to contain the package being tested. The package is placed inside the test chamber to which a vacuum is applied. Using a single or dual vacuum transducer technology, the level of vacuum as well as the change in vacuum over a predetermined test time are monitored. The variations in absolute and differential vacuum indicate the presence of leaks and defects within the package. The sensitivity of a test is a function of the package design, the package test fixture and critical test parameters of time and pressure. Test systems can be designed for manual or automatic operation. This inspection method is suitable for laboratory offline testing and production applications for QA/QC statistical process control. The test cycle takes only a few seconds, is non-invasive and non-destructive to both product and package.

Benefits of VeriPac series

• Deterministic, quantitative test method.
• Defect detection down to 0.034 cc/min.
• Highest level of repeatability and accuracy.
• Cost-effective with rapid return on investment.
• Simplifies the inspection and validation process
• Results proven superior to dye ingress.
• ASTM test method and FDA standard
• USP <1207> Compliant.

Parenteral preparations are defined as solutions, suspensions, emulsions for injection or infusion, powders for injection or infusion, gels for injection and implants. They are sterile products intended to be administrated directly into human bodies. Parenteral drug products are expected to be free from microorganisms, pyrogenic substances as well as other visible particles. Contaminated parenteral drug products can cause serious health concerns to the patient. Hence, sterility assurance and package integrity testing are of paramount importance in parenteral drug manufacturing. Read on to know more about parenteral products package testing methods offered by PTI.

Parenteral products package testing methods:

1. Vacuum Decay technology

Vacuum Decay technology is a non-destructive Container Closure Integrity test method primarily used to detect leaks in package seals. Proven to be the most practical and sensitive vacuum-based leak test method, Vacuum Decay technology is capable of identifying leaks in sealed rigid, semi-rigid and flexible packaging made of non-porous or porous materials. It provides reliable, accurate and repeatable test results that ensure deterministic package testing and leak detection. Vacuum Decay technology has established itself as a non-destructive alternative to traditional test methods like Water Bath and Dye Ingress, making it a practical solution for leak detection in the Pharmaceutical and Medical Device industry.

How does Vacuum Decay technology work?

The principle behind Vacuum Decay technology is simple and it challenges container integrity based on fundamental physical properties. The test begins by placing sample packages in a closely fitting evacuation test chamber, which is equipped with an external vacuum source. Based on the test sample and level of sensitivity required, a pre-determined vacuum level is chosen for the test. The next step involves evaluating the test chamber and test system dead space for a pre-determined period. Differential pressure transducers are used to monitor changes in vacuum levels for a specified period. A pressure increase beyond the predetermined pass/fail limit indicates container leakage.

Benefits of Vacuum Decay technology

• Non-destructive package inspection system
• Accurate and reliable results
• Definite pass/fail result based on quantitative test data
• Accommodates multiple packaging formats
• Eliminates destructive, subjective testing methods
• Effective in detecting even minute leaks
• ASTM Test Method F2338, FDA Consensus Standard and USP 1207 compliant


2. MicroCurrent HVLD Technology

PTI’s Microcurrent is patent-pending unique CCI technology that has revolutionized the conventional high voltage leak detection method. It is a non-invasive and deterministic container closure integrity testing method that is effective across all parenteral and biologic products including low conductivity liquids such as sterile water for injection. The Microcurrent HVLD test method is highly effective in detecting the presence and location of pinholes, micro-cracks, stopper/plunger leaks, non-visible leaks under crimping and many other defects across applications like pre-filled syringes, vials, cartridges, ampoules, BFS, bottles and pouches. A unique mode of Microcurrent HVLD uses about 50% less voltage and reduces the exposure of product and environment to less than 5% of the voltage when compared to conventional HVLD solutions. The E-scan HVLD series is a leading solution of sturdy container closure integrity test equipment.

Benefits of MicroCurrent HVLD technology

• Non-destructive & requires no sample preparation
• Deterministic & non-invasive
• Highly effective across all parenteral products
• High levels of sensitivity, accuracy and reliability in results
• Offline and 100% online inspection at high production speeds
• Simplifies the inspection and validation process
• Referenced in Chapter USP 1207 Guidance for CCIT

Packaging is an essential part of the pharmaceutical industry, given the sensitive nature of the contents. High-risk medications and lifesaving drugs need utmost care and protection until they reach the patient. As such, stringent industry standards apply to pharmaceutical packaging. Manufacturers give high priority to safety and quality while selecting packaging materials for a drug or healthcare product. The packaging should be able to act as a barrier against external contamination and chemical reactions. Exposure to reactive gases can alter the physical, chemical and biological attributes of the products. This makes Container Closure Integrity Testing of pharmaceutical packaging a regulatory requirement.

Role of MicroCurrent HVLD in ensuring pharmaceutical package integrity

Often referred to as the conductivity and capacitance test, High Voltage Leak Detection (HVLD) is a test method found to be highly effective in detecting the presence and location of leaks in a wide range of pharmaceutical and parenteral applications. It can be used for leak testing in nonporous, rigid or flexible packages, as well as packages containing liquid or semi-liquid products. High Voltage Leak Detection test is conducted using electrical conductivity and resistance principle. This method operates by passing high voltage micro current signals through sample packages. Under the presence of a leak, the electrical resistance of the sample declines, causing an increase in current. Compared to other leak detection methods that rely on flow of gas or liquid, HVLD technology relies on “flow” of current. This reduces challenges with defect clogging compared to flow-based analysis.

The latest evolution of HVLD, PTI’s patent pending MicroCurrent technology, aims to achieve a high level of CCI assurance across the entire range of pharmaceutical products. The MicroCurrent HVLD reduces voltage exposure to the product to less than 5% of the voltage exposure experienced when testing with comparable HVLD solutions. Reducing exposure voltage not only reduces any risk that the voltage poses to the product, but also greatly reduces the production of Ozone during operation when compared with traditional HVLD solutions. Ozone in the headspace of a container can be detrimental to the product, and in the operating environment can affect respiratory health.

Benefits:

Non-destructive Container Closure Integrity Test (CCIT)

Requires no sample preparation

Capability to test multiple packages in a single test cycle

Identifies which package is defective

Simplifies the inspection and validation process

Supports sustainable packaging initiatives

ASTM test method and FDA standard

Cost effective with rapid return on investment

Maintaining quality requirements and ensuring package integrity are important criteria for pharmaceutical product manufacturers. As such, the shift to more automated processes and digital measurement systems have systematically become a greater part of pharmaceutical manufacturing. In this blog, we will discuss automated package inspection techniques offered by PTI.

1. Vacuum Decay technology

Vacuum Decay technology is a non-destructive Container Closure Integrity Test (CCIT) used for leak detection in nonporous, rigid, or flexible packages. It is an ASTM-approved, FDA-recognized test method with proven capabilities to provide reliable, reproducible, repeatable and accurate quantitative results. This method involves drawing vacuum on the sample package kept in the test chamber and analyzing the vacuum level for any defect, indicating a leak.

Vacuum Decay technology is applicable across a wide range of pharmaceutical and medical devices with the capability of detecting leaks in single digit micron range while accommodating multiple packaging types. PTI has made further advancements in Vacuum Decay technology with its PERMA-VAC technology and VeriPac FLEX Series.

PERMA-VAC technology that addresses vacuum decay detection at the very core of physical test measurement, controlling the test system volume and maximizing the SNR between good and defective samples. It is a a single or dual vacuum transducer technology, which has higher test sensitivity for providing accurate and reliable results.

The VeriPac FLEX series, designed specifically for dry filled pouches and flexible packaging are available in several configurations with the ability to accommodate various package specifications. Each model achieves a specific range of test sensitivity and various test chamber sizes are available depending upon the package size and characteristics. The VeriPac FLEX series offer defect detection to the 10 to 20 micron range.

2. MicroCurrent HVLD Technology

PTI's MicroCurrent HVLD technology is a unique High Voltage Leak Detection Technology for container closure integrity testing. It is found to be highly effective across a wide range of high-risk pharmaceutical products and medical devices. When compared to traditional HVLD solutions, this method uses around 50% less voltage and exposes the product and environment to less than 5% of the voltage. Being a non-invasive technique it requires no sample preparation and has a high degree of reproducibility and accuracy throughout.

The Microcurrent HVLD test method can detect the presence and location of pinholes, micro-cracks, stopper/plunger leaks, non-visible leaks under crimping and many other defects. It assures product CCI by scanning a non-conductive sealed container with electrode probes. Any defect in the packaging results in resistance differential and change in current flow in the container as well as the approximate defect location.

Such automated platforms would provide the same 100% testing capability with an accurate inspection that includes quantitative test data and a pass/fail result. Proper sensory measurement requires time to capture a result. However, these new automated technologies can still reliably inspect containers at a much higher rate than was possible before, with a more sensitive leak detection capability.

According to USP1207, the headspace inside a sterile pharmaceutical or medical device packaging is an important part of a product. Therefore, it should comply with corresponding quality-relevant attributes. The attributes may vary depending on the product. For instance, the residual oxygen concentration is one of the attributes for oxygen-sensitive formulations. Testing low headspace packages like sachets and blister packages can be quite challenging for manufacturers. Read on to know how PTI's VeriPac 410 ensures package integrity of low headspace packages.

Leak testing using VeriPac 410 series.

Over the years, manufacturers of multi-cavity blister packs and low headspace packaging have been using destructive test methods to evaluate the integrity of such packages. However, such traditional test methods lacked accuracy and produced subjective, and unreliable results. In order to overcome the limitations of destructive test methods, PTI has developed VeriPac 410 inspection system - a non-destructive seal and leak detection technology for blister packs, sachets, and pouches with low headspace.

The VeriPac 410 employs a mix of vacuum decay technology and differential force measurement to identify defects in packages. Multiple packages can be tested in a single test cycle, depending on package specifications. The non-deterministic nature of the test produces accurate and reliable results, removes subjectivity and the operators can get a definite pass/fail outcome. Additionally, being a non-destructive test method, the VeriPac 410 allows tested packages to be returned to the production line and eliminates the cost and waste associated with destructive leak test methods. This test method has a wide range of applications including low volume flexible and semi-flexible package leak testing.

Technology Overview

The VeriPac 410 tester is connected to a specially designed drawer-style test chamber. A custom package insert that conforms to the package shape increases test sensitivity. Certain types of packages can be tested in multiple during a single test cycle. The location of the defective package or cavity is identified. Vacuum levels are monitored during the test cycle to evaluate the package using the ASTM F2338 vacuum decay leak test method. Decay of the vacuum level indicates that air is leaking from the package into the test chamber.

Once the vacuum testing phase is complete, a pressure plate maps the surface pressure of the flexible package lidding. The pressure plate system recognizes the pressure pattern exerted by the package when it is not defective, and the lack of pressure exerted on the pressure plate by a defect, allowing for both defect detection and location of the defective package or cavity.

Benefits of VeriPac 410 system

Non-destructive, non-invasive, no sample preparation

Non-subjective, accurate and repeatable results

Capability to test multiple packages in a single test cycle

Identifies which package is defective

Simplifies the inspection and validation process

Supports sustainable packaging initiatives

ASTM test method and FDA standard

Cost effective with rapid return on investment

Packaging has always been an indispensable factor in the pharmaceutical manufacturing process. Since most pharmaceutical products come under high-risk category, appropriate packaging is vital to prevent product deterioration. Faulty or damaged packaging can cause oxygen, moisture, microorganisms or other harmful substances to enter the product- making it unfit for use. Given the sensitive nature of pharmaceutical products, package inspection testing holds high relevance. Let us now understand what CCI techniques are being offered by PTI for pharmaceutical package testing.

Techniques to ensure CCI

1. Vacuum Decay technology

Vacuum Decay is a non-destructive Container Closure Integrity Test (CCIT) method that is highly effective in detecting leaks in nonporous, rigid and flexible packages. It is a simple test method that challenges container integrity based on fundamental physical properties. As the name suggests, this test is conducted by drawing vacuum on a package within a test chamber and monitoring the vacuum level for any decay, which would indicate a leak. The standard vacuum decay leak test method (ASTM F2338), developed using PTI's VeriPac instruments, is recognized by the FDA as a consensus standard for container closure integrity (CCI) testing. The test method is listed in ISO 11607 and referenced in the United States Pharmacopeia Chapter on CCI (USP Chapter 1207). PTI has revolutionized Vacuum Decay technology with its s next generation of improvements in the form of PERMA-VAC technology and VeriPac FLEX Series.

PERMA-VAC Technology is a single or dual vacuum transducer technology, which has higher test sensitivity for providing accurate and reliable results. This method can be applied to flexible and semi-flexible packages alike.

The VeriPac FLEX series are innovative packaging inspection systems specifically for flexible packages. These are available in different configurations to accommodate various package specifications, capable of detecting leaks down to the 10 to 20 micron range.

Benefits of Vacuum Decay technology

Non-destructive, non-subjective, no sample preparation

Capable of detecting defects down to 0.05 ccm

Accurate, reliable, repeatable results

Supports sustainable packaging and zero waste initiatives

ASTM test method F2338

2. MicroCurrent HVLD Technology

High Voltage Leak Detection (HDLV) is a Container Closure Integrity test method that utilizes high voltage leak detector system for evaluating integrity of nonporous packages. The latest evolution in the HVLD technology, PTI’s MicroCurrent HVLD is revolutionary technology, a non-destructive, non-invasive CCI technique which can precisely detect any leak in a wide range of liquid filled products including extremely low conductivity sterile water for injection (WFI) and proteinaceous products with suspensions.

This method operates by scanning a sealed container using electrode probes to detect the presence of any leak. By analyzing a change in the current flow, the test operator can detect Defect in the container as well as its approximate location. PTI's MicroCurrent HVLD uses about 50% less voltage and exposes the product and environment to less than 5% of the voltage compared to conventional HVLD technologies. This technology can be easily shifted from offline to 100% inline testing application, thereby simplifying the inspection and validation process.

Benefits of MicroCurrent HVLD technology

• Non-destructive, non-invasive, no sample preparation
• High level of repeatability and accuracy
• Effective across all parenteral products, including extremely low conductivity liquids (WFI)
• Low voltage exposure to the product and environment
• Listed in USP Chapter <1207> as recommended method for parenteral liquid package inspection
• Robust method and approximate 3x Signal-Noise-Ratio for a wide range of product classes and package formats
• Simplifies the inspection and validation process
• Offline and 100% online inspection at high production speeds

Container closure integrity testing (CCIT) or leak testing is an important process in the manufacturing phase of a pharmaceutical drug product in particular parenteral products. CCIT is performed to evaluate and maintain sterility over the shelf life of a product as well as to prevent contamination of the product from moisture, reactive gases, or micro-organisms. In earlier times, dye ingress, microbiological ingress and other probabilistic test methods were being used in the industry. However, the results produced by such methods lacked accuracy, reliability and were highly subjective. Therefore, manufacturers are now replacing probabilistic test methods with deterministic methods, which reduce the needs for sample preparation and validation and provide more accurate detection of leaks and defects.

Why is VeriPac 465 effective in highly sensitive micro leak testing?

PTI's VeriPac 465 is a deterministic, quantitative inspection technology that is non-destructive and non-invasive to the package being tested. This technology requires no sample preparation and performs leak detection based on the basic principles of physics. The VeriPac 465 is an ASTM approved, FDA recognized package integrity testing method which is based on vacuum decay leak test method (F2338). This test method was developed using VeriPac leak test instruments. Unique test cycles, pneumatic controls and processing algorithms are certain features of VeriPac 465 system that make it the foremost vacuum-based leak test for parenteral products.

This inspection method is suitable for laboratory offline testing and QA/QC statistical process control. The test cycle takes only a few seconds, results are non-subjective and testing is non-destructive to both product and package.



Technology overview

The test begins by connecting VeriPac 465 leak tester to a chamber that is specially designed to contain the package to be tested. Vacuum is then applied to the test chamber in which the package is placed. Using dual transducer technology, the test chamber is monitored for both- level of vacuum and the change in vacuum over a predetermined test time. The changes in absolute and differential vacuum indicate the presence of leaks and defects within the package. The sensitivity of a test is a function of the sensitivity of the transducer, the package design, the package test fixture and critical test parameters of time and pressure. VeriPac 465 technology reduces the baseline measurement for good samples and amplifies the test result for defective samples. This technology is geared towards detecting leaks in the MALL range for parenteral packaging and can also be applied to flexible and semi flexible package formats

Inspection Criteria

• Measures seal integrity of entire container or package
• Measures and verifies container closure system integrity
• Tests for gas leaks for dry products (lyophilized vials, powder filled)
• Tests for liquid leaks (liquid filled vials, pre-filled syringes)

Benefits of VeriPac 465

• Non-destructive, non-subjective, no sample preparation
• Defect detection down to 0.002 cc/min
• Highest level of sensitivity, repeatability and accuracy
• Results proven superior to dye ingress
• Deterministic, quantitative test method
• Supports sustainable packaging and zero waste initiatives
• ASTM test method and FDA standard

As pharmaceutical products leave the laboratory for distribution, they may be exposed to certain conditions that put their integrity at risk. Product quality deterioration and economic losses may be caused due to extreme temperatures or shocks during transportation. Pharmaceutical package inspection is vital to identify and control materials that may alter the protective capacities of packaging. Container Closure Integrity Testing of pharmaceuticals is performed with the purpose of guaranteeing the safety of the products during its distribution and storage lifecycle until delivery to the patient. CCIT helps in determining the integrity and stability of packaging or container until the point of delivery.

CCI testing using Vacuum decay technology

To guarantee integrity and consistency of packages, the ability to precisely detect leaks and defects is necessary. Although destructive Container Closure Integrity Testing (CCIT) methods like water bath, dye tests, peel and burst tests can detect leaks, they are time-consuming, unreliable and produce subjective test results. Additionally, they generate significant product loss and wastage. Over the years industry has seen an increasing demand for non-destructive package integrity testing methods. One such method is Vacuum Decay technology.

Vacuum Decay is a test method that has been proven over decades as the most practical and sensitive vacuum-based leak test method. It is a simple test method that challenges container integrity based on fundamental physical properties. Vacuum Decay technology creates reliable and accurate quantitative results with a pass or fail determination and has been established as a non-destructive deterministic alternative method to the blue dye test. The standard vacuum decay leak test method (ASTM F2338), developed using PTI's VeriPac instruments, is recognized by the FDA as a consensus standard for container closure integrity (CCI) testing. The test method is listed in ISO 11607 and referenced in the United States Pharmacopeia Chapter on CCI (USP Chapter 1207)

How does Vacuum Decay Technology work?

Under this method, the leak testers are first connected to a test chamber that is specifically designed to hold the package to be tested. Vacuum is applied to the package placed inside the test chamber. Using single or dual vacuum transducer technology test chamber and level of vacuum are monitored along with a change in vacuum over a predetermined test time. The changes in absolute and differential vacuum indicate the presence of leaks and defects within the package. This inspection method is suitable for laboratory offline testing and can be designed for manual or fully automated operation. The test cycle is non-destructive to both product and package and takes only a few seconds. It provides significant savings by not wasting products for a leak test and generates a return on investment in under six months for many products.

Key Benefits of Vacuum Decay technology

• Non-destructive and non-invasive
• No sample preparation
• ASTM approved test method
• FDA Recognized Consensus Standard
• Allows for increased sampling
• Quantitative results
• Repeatable
• Rapid test time
• Eliminates cost and waste of destructive testing
• Test results can be easily validated
• SPC laboratory testing or online applications

Medical device packaging plays a fundamental role in safeguarding the product and retaining its quality throughout its shelf life. A package containing medical devices should not only reach the hospital defect free, but it also must withstand sitting on a shelf, possibly for years, without breaking down. Therefore, medical device packaging should be in line with international regulations and quality standards. In order to ensure quality of medical device packages, manufacturers reply on package integrity and seal quality test methods. Although the market offers a complete range of inspection techniques, it is important for manufacturers to choose the appropriate one based on packaging material used and sensitivity levels required.

The ideal solution is a non-destructive method for inspecting the physical properties of the seal and a non-subjective analysis to determine the seal quality. PTI’s Airborne Ultrasound technology (ASTM Test Method F3004-13) uses a transmission of high frequency sound waves through the pouch seal area, providing a simple pass or fail result of seal quality. A linear scan analysis of the seal area will detect channel defects, misaligned seals, incomplete and missing seals immediately after the package has been sealed. If the system detects a package defect, the product can immediately be removed from the packaging and reworked. Process related defects can be addressed and corrected immediately, which significantly reduces the quantity of defective packages produced.

Package inspection using Seal-Scan technology

PTI's Seal-Scan® is a non-destructive Airborne Ultrasonic technology (ABUS) that inspects and analyzes pouch seals offline. Seal-Scan® is a semi-automatic inspection system with x-y drive, used for the detection of seal defects, seal characterization and material analysis. This technology utilizes the ASTM Test Method F3004 for seal quality and integrity evaluation. .Seal-Scan® is a deterministic, quantitative, high-resolution method that inspects pouch seals for defects and seal integrity for consistency. Testing using a Seal-Scan® is non-destructive, non-invasive, and requires no sample preparation. Seal-Scan® provides advanced digital imaging software tools for process control which offers in-depth seal quality analysis. PTI has designed several configurations of SEAL-SCAN® for both offline inspections to accommodate various package specifications, test sensitivity and package handling requirements.

Technology overview

Under this method, the pouch seal or package material is scanned between two focused ultrasonic sensors. Ultrasonic waves pass through single or multiple layers of bonded materials. Ultrasonic propagation through different mediums causes reflection of sound waves and reduces/eliminates signal strength. Seal Scan technology can detect different types of defects including leaking and non-leaking, process-related and random are detectable. This technology can produce Opto-Acoustic images as well as detailed statistical analysis by either of two scan modes (L-Scan and C-Scan). An L-Scan is a single linear scan along the X-axis of the seal that provides a line graph of seal integrity and simulates online inspection. C-Scan produces multiple scans (along X and Y-axis of seal area) that provide a high-resolution ultrasonic image of the seal structure. This technology can be integrated into a pouch production line via the Seal-Sensor for 100% on-line seal defect detection.

Benefits of Seal Scan Technology

• Deterministic inspection method producing quantitative results
• Works for any material and combinations, regardless of color transparency, print, surface finish and porosity
• Produces high resolution Opto-Acoustic image of seal
• Characterizes overall quality and uniformity of the seal

Package integrity testing may be understood as a set of techniques used to protect the contents of a package from potential physical, chemical and microbial threats. It plays a crucial role in determining and maintaining sterility and shelf life of pharmaceutical products, medical devices, and food and nutrition products. Since such products are extremely sensitive to external environmental conditions, even a minute breach in the package can cause micro-organisms, reactive gases or other harmful substances to enter the product. This can result in serious health issues to the end user and affect brand loyalty of manufacturing companies. As such, testing for leaks is an important aspect of the manufacturing process.

Historically, manufacturers relied on destructive testing methods like Water Bath or Dye Ingress as well as other unreliable methods such as Visual Inspection to test integrity of packages. However, such tests lacked accuracy and reliability in test results. Moreover, being destructive testing methods, it caused damages to the package being tested making it unfit for use. These limitations of destructive techniques prompted manufacturers to opt for non-destructive testing methods that do not harm the product and provide reliable, repeatable and quantitative rest results. Reduction in waste coupled with material cost advantage gives non-destructive methods an practical edge over destructive test methods. Examples of non-destructive testing methods include Vacuum Decay technology, Airborne Ultrasound technology and Microcurrent HVLD technology.

VeriPac test systems for precise and reliable package integrity testing

PTI’s VeriPac series are non-destructive, non-invasive inspection systems for leak detection and package integrity testing. These systems reduce waste and provide operators with a clear understanding of package quality. The VeriPac test system produces real time results from precise quantitative measurements that identify packaging defects before critical process issues get out of control. Tests can be performed in any sequence and even repeatedly on a single sample. Good packages can be returned undamaged to the packaging line. Testing is more reliable, sensitive and efficient than destructive methods. VeriPac series utilizes the ASTM approved patented Vacuum Decay leak test method F2338, recognized by the FDA as a consensus standard for package integrity testing.

Technology Overview

PTI’s VeriPac leak testers connect to a test chamber that is specially designed to contain the package to be tested. The package is placed inside the test chamber to which vacuum is applied. The absolute transducer technology is used to monitor the test chamber for both, the level of vacuum as well as the change in vacuum over a predetermined test time. The changes in absolute and differential vacuum indicate the presence of leaks and defects within the package. The test cycle takes only a few seconds, results are non-subjective, and testing is non-destructive to both product and package. The sensitivity of a test is a function of the sensitivity of the transducer, the package design, the package test fixture and critical test parameters of time and pressure. Test systems can be designed for manual or fully automated operation. This inspection method is suitable for laboratory offline testing, QA/QC statistical process control, automated batch or 100% inline testing.

Benefits of VeriPac series

• Non-destructive, non-subjective, no sample preparation
• Deterministic, quantitative test method
• Defect detection down to 0.2 ccm
• High level of sensitivity, repeatability and accuracy
• Short cycle time provides operator with PASS/FAIL result
• Small footprint and modular portable design
• ASTM test method and FDA standard
• Referenced in USP 1207 guidance

Fresh coffee is the best coffee. The quality of coffee is directly linked to freshness, and maintaining freshness requires adequate packaging. In simple words, packaging is what holds coffee products and maintains its quality. However, maintaining freshness and shelf life of packaged coffee is often a challenge for manufacturers. The flavors and oils in coffee are oxygen sensitive, while flavor profile being the key differentiator for consumers. External conditions like high temperature, light, or high humidity can increase the rate of staling. Under such conditions, whole beans will lose significant amounts of flavor and develop stale fragrance in 1-2 weeks, while in case of ground coffee the process takes 1-2 days. Compromised package integrity can result in oxidation, flavor degradation, and spoilage. Leaks as small as 10 microns can draw oxygen into the package over its shelf life. If a consumer encounters a product that exhibits oxidation, the bitterness and stale flavor will likely affect the consumer’s decision to repurchase. This explains why manufacturers give prime importance to evaluating integrity of coffee packaging.

Conventionally, water bath was the most popular technique for leak testing coffee products. Although water bath is a simple and effective leak testing method for rigid containers, it fails to meet critical needs associated with flexible coffee packages. Additionally, the cost associated with maintaining standard destructive methods is high. Subjective test results, variable test standards, and higher risks associated with the use of other methods emphasize the need for better alternatives. Hence manufacturers today opt for non-destructive testing methods that eliminate the cost associated with wasted product, and ultimately facilitate better quality control.

Package integrity testing using Vacuum Decay technology

PTI’s Vacuum Decay technology is an ASTM-approved, FDA recognized non-destructive Container Closure Integrity test method with proven capabilities to provide reliable, reproducible, repeatable and accurate quantitative results. It can detect oxygen critical leaks, providing a more reliable and sensitive solution for a range of packaging formats that is designed to protect oxygen sensitive products. This method involves drawing vacuum on the sample package kept in the test chamber, and analyzing the vacuum level for any defect-indicating a leak. VeriPac systems reliably detect leaks as small as 10 microns, identifying process issues before they become critical, avoiding costly quality deviations.

For coffee sachets, stick packs or pouches, PTI’s VeriPac FLEX series offer the highest level test sensitivity, detecting micro leaks into the single digit micron range. These are versatile non-destructive package inspection systems designed specifically for flexible packages. To accommodate various package specifications, the VeriPac FLEX is available in several configurations. Each model achieves a specific range of test sensitivity and various test chamber sizes are available depending upon the package size and characteristics. Hence, VeriPac vacuum decay is a practical alternative and significant improvement to the destructive test methods commonly used for flexible packaging.

Benefits of Vacuum Decay technology:

• Reliable and sensitive leak detection of quality critical defects
• Cost savings
• Using a non-destructive leak test method allows an increase in the number of product samples tested
• Rapid test cycle and minimal training required to operate tester
• Rapid ROI due to substantial cost savings and elimination of product loss

What is VeriCon Technology?

VeriCon system encompasses a complete line of leak testers for empty bottles and containers. It is a powerful leak detection system that operates round-the-clock to ensure high leak test sensitivity with the capability to measure down to 200 microns. Under this process, the container is filled with pressure to a certain level. The rate of pressure decay is analyzed and measured which corresponds to pressure within the container. The operating panel displays pass/fail results and the defective container is rejected from the line . With PTI’s VeriCon technology, users can choose from a wide range of leak tester configurations, according to different container specifications. Its applications include plastic, blow molding, food, beverage and pharmaceutical industries. VeriCon technology works well for small, medium to large size containers and has inspection rates upto150 bottles/min. range. According to Heinz Wolf, general manager, Packaging Technologies and Inspection “In addition to the basic inspection economics of identifying leaking containers and minimizing false rejects, VeriCon systems offer many additional advantages that increase overall operational efficiency. The Auto-learn feature for example, automates setup of accept/reject criteria. Real time inspection data with reject statistics and test result With reject statistics & test result trends, VeriCon technology ensures on demand analyses of container quality.”

VeriCon technology can be implemented using pressure decay or vacuum decay technology. Plastic containers of almost all sizes use pressure decay technology. In situations where due to specific characteristics of the container, pressure decay technology is not capable of detecting leaks, Vacuum decay technology is applicable. Depending on the line speed/hole size requirement, VeriCon testers are available in one to four station configurations.

VeriCon Configurations

• Trimmer mount: available in single and dual station configurations, VeriCon trimmer mount systems are designed precisely for indexing systems installations.
• Linear Leak Testers: available in single or multi-station configurations for standard online linear leak detection with inspection speeds up to 70 bottles/min.
• Continuous Motion Testers : available in 1 to 4 station configurations with inspection speeds up to 150 bottles/min. Continuous motion inspection’s high speed testing ensures uninterrupted inspection of containers.

Benefits of VeriCon technology:

All VeriCon systems offer the following features and benefits:

• VeriCon technology uses high-resolution non-drifting transducers thereby ensuring consistent leak detection.
• Accurate leak testing with repeatable results
• 24/7 operation
• Capable of accommodating multiple container specifications and test sensitivity requirement

Ensuring packaging quality is pivotal in all manufacturing. For efficient packaging, it is important for manufacturers to have complete knowledge of packaging material used and test sensitivity desired, so that appropriate package integrity tests can be undertaken.

Today’s healthcare industry assures treatments that were unimaginable a few years ago. As pharmaceutical industry grows in importance, the techniques of primary packaging for healthcare products, especially parenteral products has taken on new prominence. Common parenteral packaging methods include Liquid-filled containers such as vials, ampoules, syringes, blow-fill-seals and auto-injectors and containers filled with lyophilized products. Since these drugs are directly administered into human bodies, high sensitivity integrity tests are required to ensure product quality throughout its shelf life. For reasons of safety, packaging material, integrity and design are regulated by Food And Drug Administration as strictly as the product itself.

Container Closure Integrity Testing is a leak detection test conducted using a non-destructive packaging inspection system to protect the drug from any possible contamination. It is a crucial step in evaluating safety and integrity of the primary packaging so as to maintain a sterile barrier and to avoid leakage resulting in contamination of the drug. Packaging components like bottles, vials, syringes that are in direct contact with the product are called primary components while aluminum caps, cardboard boxes are secondary components as they are not in direct contact with the product. Proper packaging should be a priority for all drug products, but in case of parenteral products, these concerns amplifies several folds as they are directly injected. Hence initiating a proper container closure system is vital for product and consumer safety.

Although Container Closure Integrity Testing(CCIT) can be performed in many different ways, it can be broadly classified into Probabilistic methods and Deterministic methods. Probabilistic test methods including Microbial Challenge by Immersion, Tracer Liquid Tests (e.g. Dye Ingress), Bubble Tests etc. are traditional test methods where result accuracy may be uncertain. On the other hand, Deterministic test methods like Electrical Conductivity and Capacitance Test (HVLD), Laser-based Gas Headspace Analysis, Mass Extraction, Pressure Decay provide quantitative results with high accuracy. The United States pharmacopeia released guidance in 2016 stating that deterministic methods are preferred over probabilistic test methods.Packaging Technologies And Inspection (PTI’s) Microcurrent HVLD technology and vacuum decay technology are the latest inventions in package integrity testing of parenteral products.

1. Microcurrent HVLD Technology: Microcurrent HVLD is a unique High Voltage Leak Detection Technology, highly effective across all parenteral products. Its Applications include liquid-based products ranging from extremely low conductivity sterile water for injection (WFI) to proteinaceous products with suspensions. Its ability to detect small pinholes, micro cracks and seal defect detection down to single-digit microns makes it an ideal choice for testing parenteral products.

2. VeriPac Vacuum Decay Technology: VeriPac Vacuum Decay Technology, based on the ASTM vacuum decay leak test method (F2338-09) and accredited by the FDA for package integrity testing, is a non-destructive inspection system, capable of defect detection down to 0.002 cc/min. This system is applicable for empty and pre-filled syringes, liquid-filled and lyophilized vials and other flexible and rigid liquid-filled packaging. Depending on the package type and leak test sensitivity needed, appropriate VeriPac model can be selected.

PTI’s next generation PERMA- VAC technology addresses vacuum decay detection at the very core of physical test measurement by controlling the test system volume and maximizing the SNR between good and defective samples. This makes PERMA-VAC the most reliable vacuum-based leak test available in the market.

The global pharmaceutical industry has seen tremendous growth over the last few decades. The complex nature of the industry coupled with frequent breakthroughs has made it a favorite subject of scrutiny. Since any defect in the packaging of drugs can have serious consequences, assuring the quality of the packaging is of prime interest for every manufacturer. Pharmaceutical products are expected to be free from microbial contamination and safe to use right from production throughout their shelf-life. The drug’s stability can be adversely affected through contamination in the form of oxygen, humidity or microbiological ingress. In order to prevent such risks, integrity tests with high sensitivity are required.

Previously, only sterility testing was conducted on pharmaceutical packaging. However, when it was realized that sterility testing alone is not sufficient to hold the integrity of the medical products, the US FDA published Guidance for Industry for Submission Documentation for Sterilization Process Validation in Applications for Human and Veterinary Drug Products. This emphasised the importance of verification of microbial barrier properties of a pharmaceutical product package (i.e., CCI). FDA defines Container Closure Integrity Testing (CCIT) “as the sum of packaging components that together contain and protect the dosage form”.

Container Closure Integrity Testing is a method of leak detection using a non-destructive packaging inspection system to prevent possible contamination. Such a test is essential since any defect in the container can cause external particles to enter the product, thereby reducing its shelf life. Implementing right Container Closure System has been of prime importance for a manufacturer as it affects both the product and the patient. Hence, the relevance of CCI Testing in the pharmaceutical industry has steadily increased over the years. Contaminants that can enter a product include micro-organisms, reactive gases, and other substances. CCIT ensures product quality is maintained from the point of manufacture throughout its distribution and use. Container closure systems include primary packaging components and secondary packaging components. Components such as a glass vial or syringe, which come into direct contact with the product, are primary packaging components. On the other hand, components that are crucial to ensure correct package assembly, such as aluminum caps, over stoppers etc. are the secondary packaging components

CCI Testing Methods

Container closure integrity testing can be performed in many different ways. Each method has its own merits and demerits. A number of factors have to be considered while selecting appropriate testing methods. These factors include, but are not limited to; the reliability of the test method, material of the primary package and inline versus an offline testing requirement. CCI testing methods can also be selected depending on specific desired outcomes. Examples of desired outcome include: identifying the presence of leak paths, understanding leak path’s location, evaluating leak rate for the whole package, and measuring potential for microbial ingress. The United States pharmacopeia released guidance in 2016 stating that deterministic methods are preferred over probabilistic test method.

1. Probabilistic methods: Here, the testing methods are more traditional, and the accuracy of the result is uncertain. The probabilistic methods include the following:

• Microbial Challenge by Immersion
• Tracer Liquid Tests (e.g. Dye Ingress)
• Bubble Tests
• Tracer Gas (Sniffer Mode)

2. Deterministic methods: Such methods provide quantitative results with a higher level of accuracy. The chances of errors are also minimal. The deterministic methods include the following:

• Electrical Conductivity and Capacitance Test (HVLD)
• Laser-based Gas Headspace Analysis
• Mass Extraction
• Pressure Decay
• Tracer Gas (vacuum mode)
• Vacuum Decay
